CIP Objects
# Name Access
Alloc Control
(reserved)
Num Mcast
Mcast Start
Addr
10 SelectAcd Set
11 LastConflictDe- Set
tected
AcdActiviity
RemoteMAC
ArpPdu
12 EIP Set
QuickConnect
13 Encapsulation Set
inactivity
timeout
• Support for configuring network settings (attributes #3 and #5) from the network can be disabled by
implementing attribute #9 in the EtherNet/IP Host Object, see
• Attributes #10 and #11 will not be available if ACD is disabled using attribute #11 in the Ethernet Host
Object (F9h).
• Attribute #12:
– If the module is configured to use EIP QuickConnect functionality, the EDS file has to be changed. As
the EDS file is changed, the identity of the module has to be changed and the module will require
certification.
– This attribute exists if attribute #26 in the EtherNet/IP Host Object is implemented, see
Host Object (F8h), p.
Anybus CompactCom 40 EtherNet/IP IIoT Network Guide
Type Value
USINT 0
USINT 0
UINT -1
-
UDINT
Bool 1
Struct of:
-
USINT
ARRAY of 6 USINT -
-
ARRAY of 28
USINT
0
Bool
UINT 0 - 3600
200.
Comments
Value: Meaning:
0: Use default allocation algorithm to generate
multicast addresses
1:
Allocate multicast addresses according to the
values in the "Num Mcast"- and "Mcast Start
Addr"-fields.
Set to zero. Do not change.
Number of multicast addresses to allocate for EtherNet/IP
Starting multicast address from which to begin allocation
Value: Meaning:
0: Disable ACD
1:
Enable ACD (Default).
If ACD (address conflict detection) is enabled, bit
6 in attribute #1 will be set if an ACD conflict is
detected. The Network Status LED will also
indicate a detected conflict, see
216 .
ACD Diagnostic parameters Related to the last conflict
detected.
State of ACD activity when last conflict detected.
MAC address of remote node form the ARP PDU
in which a conflict was detected.
Copy of the raw ARP PDU in which a conflict was
detected.
Meaning:
Value:
0:
Disable EIP QuickConnect (Default)
1: Enable EIP QuickConnect
If EIP QuickConnect is enabled, the QuickConnect
feature will direct EtherNet/IP target devices to
quickly power up and join an EtherNet/IP
network.
Number of seconds of inactivity before a TCP connection is
closed.
0: Disabled
EtherNet/IP Host Object (F8h), p. 200
