Connection Manager (06H) - Anybus CompactCom 40 Network Manual

CIP Objects
12.6

Connection Manager (06h)

Category
Extended
Object Description
This object is used for connection and connectionless communications, including establishing connections
across multiple subnets.
Supported Services
Class:
Instance:
Class Attributes
(No supported class attributes)
Instance Attributes
# Name Access
1 Open Requests Set
2 Open Format Set
Rejects
3 Open Resource Set
Rejects
4 Open Other Set
Rejects
5 Close Requests Set
6 Set
Close Format
Rejects
7 Set
Close Other
Rejects
8 Connection Set
Timeouts
Anybus CompactCom 40 EtherNet/IP IIoT Network Guide
-
Get Attribute All
Get Attribute Single
Set Attribute Single
Large_Forward_Open
Forward_Open
Forward_Close
Unconnected Send (when unconnected routing is enabled)
Type
Value/Description
UINT
Number of Forward Open service requests received.
UINT Number of Forward Open service requests which were rejected due to bad
format.
UINT
Number of Forward Open service requests which were rejected due to lack of
resources.
UINT Number of Forward Open service requests which were rejected for reasons
other than bad format or lack of resources.
UINT Number of Forward Close service requests received.
UINT
Number of Forward Close service requests which were rejected due to bad
format.
UINT
Number of Forward Close service requests which were rejected for reasons
other than bad format.
UINT
Total number of connection timeouts that have occurred in connections
controlled by this Connection Manager.
105 (244)
SCM-1202–069 1.9 en-US
