Anybus CompactCom 40 Network Manual page 62

JSON
update.json
POST adi/update.json
Form data:
inst=<instance>&value=<data>[&elem=<element>][&callback=<function>]
Updates the value attribute of an ADI.
Request data:
Name
inst
value
elem
callback
Response data:
Name
result
{
"result" : 0
}
Anybus CompactCom 40 EtherNet/IP IIoT Network Guide
Data Type
Description
Number Instance number of the ADI
String Value to set.
If the value attribute is a number it shall be hes formatted, see
Format Explained, p. 71
Number Optional.
If specified only a single element of the ADI value is set. Then <data>
shall only contain the value of the specified <element>.
String Optional.
A callback function for JSONP output.
Data Type Note
Number 0 = success
The Anybus CompactCom error codes are used. Please see the Anybus
CompactCom 40 Software Design Guide.
for more information.
SCM-1202–069 1.9 en-US
60 (244)
Hex
