CIP Objects
12.13

Port Object (F4h)

Category
Extended
Object Description
The Port Object describes the CIP ports present on the device. Each routable CIP port is described in a separate
instance. Non-routable ports may be described. Devices with a single CIP port are not required to support this
object.
The object exists only if enabled in the EtherNet/IP Host Object (Instance Attribute #17).
See also ..
• EtherNet/IP Host Object (F8h), p. 200
• CIP Port Configuration Object (0Dh), p. 172
Supported Services
Class:
Instance:
Class Attributes
# Name Access
1 Revision Get
2 Max Instance Get
3 Get
Number of
Instances
8 Entry Port Get
9 Port Instance Get
Info
Anybus CompactCom 40 EtherNet/IP IIoT Network Guide
(Anybus Module Object)
(Host Application Object)
Get_Attributes_All
Get_Attribute_Single
Get_Attributes_All
Get_Attribute_Single
Type Value
UINT
0002h (Object revision)
UINT
Max. instance number
UINT
Number of ports currently created.
UINT
Returns the instance of the Port Object that describes the port through which
this request entered the device.
Array of: Array of structures containing instance attributes 1 and 2 from each instance.
The array is indexed by instance number, up to the maximum number of
instances. The value at index 1 (offset 0) and any non-instantiated instances will
be zero.
Struct of:
Enumerates the type of port (see instance attribute #1)
UINT (Type) CIP port number associated with this port (see instance attribute #2)
UINT (Number)
120 (244)
