Anybus Module Objects
Instance Attributes (Instance #13, SMTP Server)
This instance holds the SMTP server address. Changes are valid after reset.
# Name
1 Name
2 Data type
3
Number of elements
4 Descriptor
5 Value
6 Configured Value
Instance Attributes (Instance #14, SMTP User)
This instance holds the user name for the SMTP account. Changes are valid after reset.
# Name
1 Name
2 Data type
3
Number of elements
4 Descriptor
5 Value
6 Configured Value
Instance Attributes (Instance #15, SMTP Password)
This instance holds the password for the SMTP account. Changes are valid after reset.
# Name
1 Name
2 Data type
3 Number of elements
4 Descriptor
5
Value
6
Configured Value
Instance Attributes (Instance #16, MDI 1 Settings )
This instance holds the settings for MDI/MDIX 1. Changes have immediate effect.
Anybus CompactCom 40 EtherNet/IP IIoT Network Guide
Access Data Type Description
Get
Array of CHAR "SMTP server"
(Multilingual, see page 145)
Get UINT8
07h (= CHAR)
Get UINT8
40h (64 elements)
Get UINT8
07h (read/write/shared access)
Array of CHAR If read, the actual value will be received. If written, the written value
Get/Set
is reflected in attribute #6 until a reset.
SMTP server address, 64 characters.
Get Array of CHAR Holds the configured value, which will be written to attribute #5 after
the module has been reset.
SMTP server address, 64 characters.
Access Data Type Description
Get
Array of CHAR "SMTP user"
(Multilingual, see page 145)
Get UINT8
07h (= CHAR)
Get UINT8
40h (64 elements)
Get UINT8
07h (read/write/shared access)
Get/Set Array of CHAR If read, the actual value will be received. If written, the written value
is reflected in attribute #6 until a reset.
SMTP account user name, 64 characters
Get Array of CHAR Holds the configured value, which will be written to attribute #5 after
the module has been reset.
SMTP account user name, 64 characters
Access Data Type Description
Get
Array of CHAR "SMTP Pswd"
(Multilingual, see page 145)
Get UINT8
07h (= CHAR)
Get UINT8 40h (64 elements)
Get UINT8
07h (read/write/shared access)
Get/Set Array of CHAR If read, the actual value will be received. If written, the written value
is reflected in attribute #6 until a reset.
SMTP account password, 64 characters
Get
Array of CHAR Holds the configured value, which will be written to attribute #5 after
the module has been reset.
SMTP account password, 64 characters
