Anybus Module Objects
Instance Attributes (Instance #1)
# Name
1 Port Type
2 Port Number
3
Link Path
4 Port Name
-
5
-
6
7
Node Address
8 Port Node Range
Anybus CompactCom 40 EtherNet/IP IIoT Network Guide
Access Data Type Description
Enumerates the port (See CIP specification, available from
Set UINT16
www.odva.org)
Set UINT16 CIP port number associated with this port
Set
Array of UINT8 Logical path segments which identify the object for this port.
Set Array of CHAR String (max. no. of characters is 64) which names the port.
- -
(reserved)
- -
(reserved)
Set
Array of UINT8 Node number of this device on port. The data type restricts the range
to a Port Segment. The encoded port number must match the value
specified in attribute #2.
A device which does not have a node number on the port can specify
a zero length node address within the Port Segment (i.e. 10h 00h).
In case the node address changes during runtime, the host application
is responsible for updating this attribute as well.
Set Struct of: Minimum and maximum node number on port.
UINT16 (Min) Support for this attribute is conditional; the attribute shall be
supported provided that the node number can be reported within the
UINT16 (Max)
range of the data type (e.g. DeviceNet). If not (as is the case with
networks such as EtherNet/IP which uses a 4 byte IP address), the
attribute shall not be supported.
