Host Application Objects
# Name Access
17 IP address byte 0–2 Get
18 Get
Ethernet PHY
Configuration
20 SNMP read-only Get
community string
21 Get
SNMP read-write
community string
22 DHCP Option 61 Get
source
23 DHCP Option 61 Get
generic string
24 Enable DHCP Client Get
Network Status
This attribute holds a bit field which indicates the overall network status as follows:
Bit Contents
0
Link
1
IP established
2 (reserved)
3
Link port 1
4
Link port 2
5... 15
(reserved)
Anybus CompactCom 40 EtherNet/IP IIoT Network Guide
Data Type Default Value
Array of UINT8 [0] = 192
[3]
[1] = 168
[2] = 0
Array of BITS16 0x0000 for
each port
Array of CHAR "public"
Array of CHAR "private"
ENUM
0 (Disabled)
Array of UINT8 N/A
BOOL 1 = True
Description
Current global link status
1= Link sensed
0= No link
1 = IP address established
0 = IP address not established
(mask off and ignore)
Current link status for port 1
1 = Link sensed
0 = No link
Current link status for port 2
1 = Link sensed
0 = No link
(mask off and ignore)
Comment
First three bytes in IP address. Used in standalone shift register
mode if the configuration switch value is set to 1-245. In that
case the IP address will be set to:
Y[0].Y[1].Y[2].X
Where Y0-2 is configured by this attribute and the last byte X
by the configuration switch.
Ethernet PHY configuration bit field. The length of the array
shall equal the number of Ethernet ports of the product. Each
element represents the configuration of one Ethernet port
(element #0 maps to Ethernet port #1, element #1 maps to
Ethernet port #2 and so on).
Note: Only valid for EtherNet/IP and Modbus-TCP devices.
Bit 0:
Auto negotiation fallback duplex
0 = Half duplex
1 = Full duplex
Bit 1–15:
Reserved
Note: This attribute is only valid for PROFINET devices.
Sets the SNMP read-only community string. Max length is 32.
Note: This attribute is only valid for PROFINET devices.
Sets the SNMP read-write community string. Max length is 32.
Note: This attribute is currently only valid for Ethernet/IP
devices.
See below (DHCP Option 61, Client Identifier)
Note: This attribute is currently only valid for Ethernet/IP
devices.
See below (DHCP Option 61, Client Identifier)
Note: This attribute is currently valid for Ethernet/IP and
PROFINET devices.
Enable/disable DHCP Client functionality
0: DHCP Client functionality is disabled
1:
DHCP Client functionality is enabled
Comment
EtherCAT only: This link status indicates whether the
Anybus CompactCom is able to communicat using
Ethernet over EtherCAT (EoE) or not. That is, it
indicates the status of the logical EoE port link and is
not related to the link status on the physical EtherCAT
ports.
Not used for EtherCAT
