Host Application Objects
# Name
1 Vendor ID
2 Device Type
3 Product Code
4 Revision
5
Serial Number
6 Product Name
Extended
# Name
7
Producing Instance No.
8 Consuming Instance No. Get
9
Enable communication
settings from net
11
Enable CIP forwarding
12 Enable Parameter
Object
13 Input-Only heartbeat
instance number
14
Listen-Only heartbeat
instance number
15
Assembly object
Configuration instance
number
16 Disable Strict IO Match
Anybus CompactCom 40 EtherNet/IP IIoT Network Guide
Access Data Type Default Value
Get UINT16 005Ah
Get UINT16 002Bh
Get UINT16 0037h
Get struct of:
(software revision)
UINT8 Major
UINT8 Minor
Get UINT32
(set at production)
Get Array of CHAR "Anybus CompactCom 40
EtherNet/IP(TM)"
Access Data Type
Default
Value
-
Get
Array of
UINT16
-
Array of
UINT16
Get BOOL True
Get BOOL False
Get BOOL True
Get UINT16 0003h
Get UINT16
0004h
Get UINT16
0005h
Get BOOL False
Comment
These values are set in the Identity Object
(CIP) at startup.
See also...
• Network Identity, p. 10
• Identity Object (01h), p. 98
Please note that changing any of these
attributes requires a new Vendor ID.
Comment
The values in this array are the EtherNet/IP Assembly
instance numbers that matches the host application
Assembly Mapping Object instances that are listed in
attribute #11 (Write PD Instance List). If the Assembly
Mapping Object is not implemented, one element in this
array is allowed, to set the producing instance number.
The maximum number of entries in the array is 6.
See "Multiple Assembly Instances" below for an example.
The values in this array are the EtherNet/IP Assembly
instance numbers that matches the host application
Assembly Mapping Object instances that are listed in
attribute #12 (Read PD Instance List). If the Assembly
Mapping Object is not implemented, one element in this
array is allowed, to set the consuming instance number.
The maximum number of entries in the array is 6.
See "Multiple Assembly Instances" below for an example.
Meaning
Value
True
Can be set from network
False Cannot be set from network
See also ...
• TCP/IP Interface Object (F5h), p. 122
• Ethernet Link Object (F6h), p. 125
• Network Configuration Object (04h), p.
Module Object)
Value Meaning
True
Requests to unknown CIP objects and unknown
assembly object instances are routed to the
application.
False Requests to unknown CIP objects and unknown
assembly object instances are not routed to the
application.
See also.command details for Process _CIP_Object_Request
below
Value Meaning
True Enable CIP Parameter Object
False Disable CIP Parameter Object
See "Instance 03h Attributes (Heartbeat, Input-Only)" in
Assembly Object (04h), p. 102 (CIP-object).
See "Instance 04h Attributes (Heartbeat, Listen-Only)" in
Assembly Object (04h), p. 102 (CIP-object).
See "Instance 05h Attributes (Configuration Data)" in
Assembly Object (04h), p. 102 (CIP-object).
If true, the module will accept Class1 connection requests
that have sizes that's less than or equal to the configured IO
sizes.
201 (244)
(CIP-object)
CIP-object)
