Anybus CompactCom 40 Network Manual page 123

CIP Objects
Instance Attributes (Instance #1)
# Name Access
1 Port Type Get
2 Port Number Get
3 Get
Link Object
4 Port Name Get
5 Port Type Get
Name
6 Port Get
Description
7
Node Address Get
10 Port Routing Get
Capabilities
See also...
CIP Port Configuration Object (0Dh), p. 172
Instance Attributes (Instances #2... #8)
# Name Access
1 Port Type Get
2 Get
Port Number
3 Get
Link Object
4 Port Name Get
5 Port Type
Get
Name
6 Port Get
Description
7 Node Address Get
8 Port Node Get
Range
10 Port Routing Get
Capabilities
See also...
CIP Port Configuration Object (0Dh), p. 172
Anybus CompactCom 40 EtherNet/IP IIoT Network Guide
Type
Value/Description
UINT
0h (default)
4h (if the application registers a port)
UINT 2h
-
Struct of:
2h (Path Length)
UINT
20 F5 24 01h (Link Path)
Padded EPATH
SHORT_STRING
"EtherNet/IP"
SHORT_STRING
""
SHORT_STRING
""
-
Padded EPATH
UDINT 1h (Routing of incoming Unconnected Messaging supported)
Type
Value/Description
UINT
Enumerates the type of port
UINT
CIP port number associated with this port
-
Struct of:
Path length (number of 16-bit words)
UINT
Logical path segments which identify the object for this port. The path must
Padded EPATH
consist of one logical class segment and one logical instance segment. The
maximum size is 12 bytes.
SHORT_STRING
Name of port, e.g. "Port A". Max. 64 characters.
SHORT_STRING ""
SHORT_STRING ""
Padded EPATH Node number of this device on port. The range within this data type is
restricted to a Port Segment.
-
Struct of:
Min. node number on port
UINT (Min.)
Max. node number on port
UINT (Max.)
UDINT
1h (Routing of incoming Unconnected Messaging supported)
, "Instance Attributes.".
