Chapter III. Virtual Function Network (vNIC)
[root@host~]# chelsio_adapter_config.py
Chelsio adapter detected
|------------------------------------|
| Choose Chelsio card:
| 1. T580_SO_CR
| 2. T6225_SO
|------------------------------------|
Select card: 2
Card T6225_SO(4:0.0) selected
|------------------------------------|
| Choose option
| 1. Change to Default settings
| 2. Change Adapter Config settings
|------------------------------------|
Select option: 2
Changing Adapter Config settings
|------------------------------------|
| Possible Chelsio adapter settings: |
| 1: 248 VFs mode
|------------------------------------|
248 VF setting selected
iii. Instantiate virtual functions:
[root@host~]# modprobe cxgb4
[root@host~]# echo n >
/sys/class/net/ethX/device/driver/<bus_id>/sriov_numvfs
•
124 virtual functions can be instantiated on T5 adapter, with 31 virtual functions per
physical function{pf 0..3}.
•
248 virtual functions can be instantiated on T6 adapter, with 62 virtual functions per
physical function{pf 0..3}.
iv. Unload the vNIC driver on the host (if loaded):
[root@host~]# rmmod cxgb4vf
v. The virtual functions can now be assigned to virtual machines (guests).
vi. For each PF on which VFs are instantiated, 1 management interface (mgmtpfX,Y) will be
created. You can see them using ip link show command:
Chelsio Unified Wire for Linux
|
3:0.0 |
4:0.0 |
|
|
|
|
