Chapter XXII. Ring Backbone

If you want to use tunnel in ring configuration, apply filter as:

[root@host~]# cxgbtool <port0_interface> configure_ringbb pf 4 vi <vf_id>

mvi <mirror_vf_id> tunnel <tunnel_interface_name>

For more ring back bone configuration options, please run

refer to the configure_ringbb section.

vi. Press any key when prompted to complete the configuration. You should be able to run traffic

between the machines/nodes now.

Automatic reconfiguration is currently not supported. In case the ring is broken,

you will need to manually configure the affected host using above mentioned

Chelsio Unified Wire for Linux

man cxgbtool
