Chapter XX. Classification and Filtering
Tos : Type of Service
protocol : IP protocol number (ICMP=1, TCP=6, UDP=17, etc)
Ethertype : Layer 2 EtherType
Macmatch :MAC index in MPS TCAM
mpshittype :MAC address "match type" (none, unicast, multicast, promiscuous, broadcast)
fragmentation :Fragmented IP packets
Supported Filter Combinations
The following combination is set by default and packets will be matched accordingly:
•
For T5/T6:
filterMode = fcoemask, srvrsram, fragmentation, mpshittype, protocol, vlan,
port, fcoe
•
For T4:
filterMode = fragmentation, mpshittype, protocol, vlan, port, fcoe
Serial #
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
Chelsio Unified Wire for Linux
fragmentation, mpshittype, macmatch, ethertype, protocol, port
fragmentation, mpshittype, macmatch, ethertype, protocol, fcoe
fragmentation, mpshittype, macmatch, ethertype, tos, port
fragmentation, mpshittype, macmatch, ethertype, tos, fcoe
fragmentation, mpshittype, macmatch, ethertype, port, fcoe
fragmentation, mpshittype, macmatch, protocol, tos, port, fcoe
fragmentation, mpshittype, macmatch, protocol, vlan, fcoe
fragmentation, mpshittype, macmatch, protocol, vnic_id, fcoe
fragmentation, mpshittype, macmatch, tos, vlan, fcoe
fragmentation, mpshittype, macmatch, tos, vnic_id, fcoe
fragmentation, mpshittype, macmatch, vlan, port, fcoe
fragmentation, mpshittype, macmatch, vnic_id, port, fcoe
fragmentation, mpshittype, ethertype, protocol, tos, port, fcoe
fragmentation, mpshittype, ethertype, vlan, port
fragmentation, mpshittype, ethertype, vlan, fcoe
fragmentation, mpshittype, ethertype, vnic_id, port
fragmentation, mpshittype, ethertype, vnic_id, fcoe
fragmentation, mpshittype, protocol, tos, vlan, port
fragmentation, mpshittype, protocol, tos, vlan, fcoe
fragmentation, mpshittype, protocol, tos, vnic_id, port
fragmentation, mpshittype, protocol, tos, vnic_id, fcoe
fragmentation, mpshittype, protocol, vlan, port, fcoe
fragmentation, mpshittype, protocol, vnic_id, port, fcoe
fragmentation, mpshittype, tos, vlan, port, fcoe
Filter Combination
