Chapter XX. Classification and Filtering
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
Using any other filter mode combination is strictly not supported.
Important
Changing default filter mode
Based on your requirement, you can change the default filter mode to any one of the combinations
mentioned in the table above. To do so, replace the default mode with the chosen mode in
firmware configuration file (t6-config.txt for T6 adapters; t5-config.txt for T5 adapters) located in
/lib/firmware/cxgb4/.
For example, if you want to filter traffic based on ethtype value in the packets for T6 adapters,
replace the default filterMode,
filterMode = fcoemask, srvrsram, fragmentation, mpshittype, protocol, vlan,
port, fcoe
with
filterMode = fragmentation, mpshittype, macmatch, ethertype, protocol, port
Chelsio Unified Wire for Linux
fragmentation, mpshittype, tos, vnic_id, port, fcoe
fragmentation, mpshittype, vlan, vnic_id, fcoe
fragmentation, macmatch, ethertype, protocol, port, fcoe
fragmentation, macmatch, ethertype, tos, port, fcoe
fragmentation, macmatch, protocol, vlan, port, fcoe
fragmentation, macmatch, protocol, vnic_id, port, fcoe
fragmentation, macmatch, tos, vlan, port, fcoe
fragmentation, macmatch, tos, vnic_id, port, fcoe
fragmentation, ethertype, vlan, port, fcoe
fragmentation, ethertype, vnic_id, port, fcoe
fragmentation, protocol, tos, vlan, port, fcoe
fragmentation, protocol, tos, vnic_id, port, fcoe
fragmentation, vlan, vnic_id, port, fcoe
mpshittype, macmatch, ethertype, protocol, port, fcoe
mpshittype, macmatch, ethertype, tos, port, fcoe
mpshittype, macmatch, protocol, vlan, port
mpshittype, macmatch, protocol, vnic_id, port
mpshittype, macmatch, tos, vlan, port
mpshittype, macmatch, tos, vnic_id, port
mpshittype, ethertype, vlan, port, fcoe
mpshittype, ethertype, vnic_id, port, fcoe
mpshittype, protocol, tos, vlan, port, fcoe
mpshittype, protocol, tos, vnic_id, port, fcoe
mpshittype, vlan, vnic_id, port
