1.1 How to Read This Programming Guide

1.1.1 Purpose of the Manual

The FC 360 Programming Guide provides information
about controlling the frequency converter, parameter
access, programming, and troubleshooting.
The Programming Guide is intended for use by qualified
personnel who are familiar with the FC 360 frequency
converter.
Read the instructions before programming and follow the
procedures in this manual.
®
VLT is a registered trademark.

1.1.2 Document and Software Version

This manual is regularly reviewed and updated. All
suggestions for improvement are welcome. Table 1.1 shows
the document version and the corresponding software
version.
Edition Remarks
MG06C4 Replaces MG06C3
6
Programming Guide
Software version
1.3X
Danfoss A/S © Rev. 2014-03-31 All rights reserved.

1.1.3 Abbreviations and Conventions

AC Alternating current
AEO Automatic Energy Optimisation
AWG American Wire Gauge
AMA Automatic Motor Adaptation
°C
Degrees Celsius
DC Direct current
EMC Electromagnetic compatibility
ETR Electronic thermal relay
f
Nominal motor frequency
M,N
FC Frequency converter
HO High overload
IP Ingress protection
I Current limit
LIM
I Rated inverter output current
INV
I Nominal motor current
M,N
I Maximum output current
VLT,MAX
Rated output current supplied by the
I
VLT,N
frequency converter
LCP Local Control Panel
N.A. Not applicable
NO Normal overload
P Nominal motor power
M,N
PCB Printed circuit board
PE Protective earth
PELV Protective Extra Low Voltage
PM motor Permanent magnet motor
Regen Regenerative terminals
RPM Revolutions per minute
T Torque limit
LIM
U Nominal motor voltage
M,N
Table 1.1 Abbreviations
Conventions
•
Numbered lists indicate procedures.
•
Bullet lists indicate other information and
description of illustrations.
•
Italicised text indicates:
- cross reference
- link
- footnote
- parameter name, parameter group
name, parameter option
MG06C402
