Parameter Descriptions
16-60 Digital Input
Range: Function:
Bit Unused
0
Bit Unused
1
Bit Digital input term. 29
2
Bit Digital input term. 27
3
Bit Digital input term. 19
4
Bit Digital input term. 18
5
Bit Unused
6-1
5
Table 4.8 Bits Definition
16-61 Terminal 53 Setting
Option: Function:
View the setting of input terminal 53.
[0] Current mode
[1] Voltage mode
16-62 Analog Input 53
Range: Function:
1 [0 - 20 ] View the actual value at input 53.
*
16-63 Terminal 54 Setting
Option: Function:
View the setting of input terminal 54.
[0] Current mode
[1] Voltage mode
16-64 Analog Input AI54
Range: Function:
1 [0 - 20 ] View the actual value at input 54.
*
16-65 Analog Output 42 [mA]
Range: Function:
0 mA [0 - 20 View the actual value at output 42. The
*
mA] value shown reflects the selections in
6-90 Terminal 42 Mode and
parameter 6-91 Terminal 42 Analog Output.
16-66 Digital Output
Range: Function:
0 [0 - 15 ] View the binary value of all digital outputs.
*
MG06C402
Programming Guide
16-67 Pulse Input #29 [Hz]
Range:
0 [0 - 130000 ] View the actual frequency rate on terminal 29.
*
16-68 Pulse Input 33 [Hz]
Range:
0 [0 - 130000 ] View the actual value of the frequency
*
16-69 Pulse Output 27 [Hz]
Range:
0 [0 - 40000 ] View the actual value of impulses applied to
*
16-70 Pulse Output 29 [Hz]
Range:
0 [0 - 40000 ] View the actual value of pulses to terminal 29
*
16-71 Relay Output
Range:
0 [0 - 65535 ]
*
16-72 Counter A
Range:
0 [-32768 -
*
32767 ]
16-73 Counter B
Range:
0 [-32768 -
*
32767 ]
16-79 Analog Output AO45
Range:
0 mA
*
Danfoss A/S © Rev. 2014-03-31 All rights reserved.
Function:
Function:
applied at terminal 33 as an impulse input.
Function:
terminal 27 in digital output mode.
Function:
in digital output mode.
Function:
View the settings of all relays.
Function:
View the present value of Counter A. Counters
are useful as comparator operands, see
parameter 13-10 Comparator Operand.
The value can be reset or changed either via
digital inputs (parameter group 5-1* Digital
Inputs) or by using an SLC action
(parameter 13-52 SL Controller Action).
Function:
View the present value of Counter B. Counters
are useful as comparator operands
(parameter 13-10 Comparator Operand).
The value can be reset or changed either via
digital inputs (parameter group 5-1* Digital
Inputs) or by using an SLC action
(parameter 13-52 SL Controller Action).
Function:
[0 - 20 mA]
