Danfoss VLT AutomationDrive FC 360 Programming Manual page 74

Parameter Descriptions
8-50 Coasting Select
Option:
[3] Logic OR
*
8-51 Quick Stop Select
Select control of the Quick Stop function via the terminals
4 4
(digital input) and/or via the bus.
Option:
[0]
[1]
[2]
[3]
*
8-52 DC Brake Select
Option:
[0] Digital
input
[1] Bus
[2] Logic
AND
[3] Logic OR
8-53 Start Select
Option:
[0] Digital
input
[1] Bus
[2] Logic
AND
[3] Logic OR
*
72
Programming Guide
Function:
Activates Start command via the fieldbus/serial
communication port OR via one of the digital
inputs.
Function:
Digital input
Bus
Logic AND
Logic OR
Function:
Select control of the DC brake via the terminals
(digital input) and/or via the fieldbus.
NOTICE
Only selection [0] Digital input is available
when 1-10 Motor Construction is set to [1]
PM non-salient SPM.
Activates Start command via a digital input.
Activates Start command via the serial communi-
cation port or fieldbus option.
Activates Start command via the fieldbus/serial
communication port, AND additionally via one of
the digital inputs.
Activates Start command via the fieldbus/serial
communication port OR via one of the digital
inputs.
Function:
Select control of the frequency converter start
function via the terminals (digital input) and/or
via the fieldbus.
Activates start command via a digital input.
Activates start command via the serial
communication port or fieldbus option.
Activates start command via the fieldbus/serial
communication port, AND additionally via one
of the digital inputs.
Activates start command via the fieldbus/serial
communication port OR via one of the digital
inputs.
Danfoss A/S © Rev. 2014-03-31 All rights reserved.
8-54 Reversing Select
Option: Function:
[0] Digital Select control of the frequency converter
input reverse function via the terminals (digital input)
and/or via the fieldbus.
[1] Bus Activates the Reverse command via the serial
communication port or fieldbus option.
[2] Logic Activates the Reverse command via the
AND fieldbus/serial communication port, AND
additionally via one of the digital inputs.
[3] Logic OR Activates the Reverse command via the
*
fieldbus/serial communication port OR via one
of the digital inputs.
8-55 Set-up Select
Option: Function:
Select control of the frequency converter set-up
selection via the terminals (digital input) and/or
via the fieldbus.
[0] Digital Activates the set-up selection via a digital input.
input
[1] Bus Activates the set-up selection via the serial
communication port or fieldbus option.
[2] Logic Activates the set-up selection via the fieldbus/
AND serial communication port, AND additionally via
one of the digital inputs.
[3] Logic OR Activate the set-up selection via the fieldbus/
*
serial communication port OR via one of the
digital inputs.
8-56 Preset Reference Select
Option: Function:
Select control of the preset reference selection
via the terminals (digital input) and/or via the
fieldbus.
[0] Digital Activates preset reference selection via a digital
input input.
[1] Bus Activates preset reference selection via the
serial communication port or fieldbus option.
[2] Logic Activates preset reference selection via the
AND fieldbus/serial communication port, AND
additionally via one of the digital inputs.
[3] Logic OR Activates the preset reference selection via the
*
fieldbus/serial communication port OR via one
of the digital inputs.
MG06C402
