Parameter Descriptions

4.11.3 12-8* Other Ethernet Services

12-80 FTP Server
Option:
[0]
*
[1]
12-81 HTTP Server
4 4
Option:
[0]
*
[1]
12-82 SMTP Service
Option:
[0]
*
[1]
12-89 Transparent Socket Channel Port
Range:
4000 [0 - 65535 ] Configures the TCP port-number for the
*

4.11.4 12-9* Advanced Ethernet Services

12-90 Cable Diagnostic
Option:
[0] Disabled
*
[1] Enabled
12-91 Auto Cross Over
Option:
[0] Disabled Disables the auto cross-over function.
[1] Enabled Enables the auto cross-over function.
*
80
Function:
Disabled
Enabled
Function:
Disabled
Enabled
Function:
Disabled
Enabled
Function:
transent socket channel. This enables FC-
telegrams to be sent transently on Ethernet
via TCP. Default value is 4000, 0 means
disabled.
Function:
Enables/disables advanced cable diagnosis
function. If enabled, the distance to cable errors
can be read out in parameter 12-93 Cable Error
Length. The parameter resumes to the default
setting of Disable after the diagnostics have
finished.
NOTICE
The cable diagnostics function is only
issued on ports where there is no link (see
parameter 12-10 Link Status)
Function:
NOTICE
Disabling of the auto cross-over function
requires crossed Ethernet cables for daisy-
chaining the options.
Danfoss A/S © Rev. 2014-03-31 All rights reserved.
Programming Guide
12-92 IGMP Snooping
Option:
[0]
[1]
*
12-93 Cable Error Length
Range:
0 [0 -
*
65535 ]
12-94 Broadcast Storm Protection
Range:
-1
% 20 %]
*
12-95 Broadcast Storm Filter
Option:
[0] Broadcast only
*
[1] Broadcast &
Multicast
12-96 Port Config
Option:
[0]
[1]
[2]
[10]
[11]
[254]
[255]
Function:
Disabled
Enabled
Function:
If cable diagnostics is enabled in
parameter 12-90 Cable Diagnostic, the built-in
switch is possible via Time Domain Reflectometry
(TDR). This is a measurement technique which
detects common cabling problems such as open
circuits, short circuits and impedance mismatches
or breaks in transmission cables. The distance from
the option to the error is displayed in metres with
an accuracy of 2 m. The value 0 means no errors
detected.
Function:
[-1 - The built-in switch is capable of protecting the
switch system from receiving too many broadcast
packages, which can use up network resources. The
value indicates a percentage of the total
bandwidth that is allowed for broadcast messages.
Example:
"OFF" means that the filter is disabled - all
broadcast messages are passed through. The value
"0%" means that no broadcast messages are
passed through. A value of "10%" means that 10%
of the total bandwidth is allowed for broadcast
messages, if the amount of broadcast messages
increases above the 10% threshold, they are
blocked.
Function:
Applies to parameter 12-94 Broadcast
Storm Protection; if the Broadcast Storm
Protection should also include Multicast
telegrams.
Normal
Mirror Port 1 to 2
Mirror Port 2 to 1
Port 1 disabled
Port 2 disabled
Mirror Int. Port to 1
Mirror Int. Port to 2
Function:
MG06C402
