Parameter Descriptions

4.18 Parameters: 21-** Ext. Closed Loop

21-09 Extended PID Enable
Option:
[0] Disabled
*
[1] Enabled Ext CL1 PID
21-11 Ext. 1 Minimum Reference
Range:
0 ExtPID1Unit [ -999999.999 - 999999.999
*
ExtPID1Unit]
21-12 Ext. 1 Maximum Reference
Range:
100 ExtPID1Unit [ -999999.999 - 999999.999
*
ExtPID1Unit]
21-13 Ext. 1 Reference Source
Option:
[0] No function
*
[1] Analog Input 53
[2] Analog Input 54
[7] Frequency input 29
[8] Frequency input 33
21-14 Ext. 1 Feedback Source
Option:
[0] No function
*
[1] Analog Input 53
[2] Analog Input 54
[3] Frequency input 29
[4] Frequency input 33
21-15 Ext. 1 Setpoint
Range:
0 ExtPID1Unit [-999999.999 - 999999.999
*
ExtPID1Unit]
21-17 Ext. 1 Reference [Unit]
Range:
0 ExtPID1Unit [-999999.999 - 999999.999
*
ExtPID1Unit]
21-18 Ext. 1 Feedback [Unit]
Range:
0 ExtPID1Unit [-999999.999 - 999999.999
*
ExtPID1Unit]
21-19 Ext. 1 Output [%]
Range:
0 % [0 - 100 %]
*
21-20 Ext. 1 Normal/Inverse Control
Option:
[0] Normal
*
[1] Inverse
MG06C402
Programming Guide
0.01
Function:
10000 s
Function:
0 s
Function:
5
Function:
Function:
Function:
Function:
Function:
Function:
Function:
Danfoss A/S © Rev. 2014-03-31 All rights reserved.
21-21 Ext. 1 Proportional Gain
Range:
[0 - 10 ]
*
21-22 Ext. 1 Integral Time
Range:
[0.01 - 10000 s]
*
21-23 Ext. 1 Differentation Time
Range:
[0 - 10 s]
*
21-24 Ext. 1 Dif. Gain Limit
Range:
[1 - 50 ]
*
Function:
Function:
Function:
Function:
