Parameter Descriptions
37-44 Line Acceleration Feed Forward
Range:
0 [-20 - 20 ]
*
37-45 Line Speed Source
Option:
[0] No function
*
[1] 24V encoder
[2] MCB102
[3] MCB103
[4] Analog input 53
[5] Analog input 54
[6] Frequency input 29
[7] Frequency input 33
37-46 Winder Speed Match Scale
Range:
1 [0.001 - 1000 ]
*
37-47 Tension PID Profile
Range:
0 % [0 - 100 %]
*
37-48 Tension PID Proportional Gain
Range:
0 [0 - 10 ]
*
37-49 Tension PID Derivate Time
Range:
0 s [0 - 20 s]
*
37-50 Tension PID Integral Time
Range:
501 s [0.01 - 501 s]
*
37-51 Tension PID Out Limit
Range:
0 % [0 - 100 %]
*
37-52 Tension PID Der Gain Limit
Range:
5 [1 - 50 ]
*
37-53 Tension PID Anti Windup
Option:
[0] Disabled
[1] Enabled
*
37-54 Winder Jog Reverse
Option:
[0] No Function
*
[1] Jog reverse
37-55 Winder Jog Forward
Option:
[0] No function
*
MG06C402
Programming Guide
Function:
[1]
Function:
[0]
[1]
[0]
[1]
[0]
Function:
[1]
Function:
[0]
[1]
Function:
Function:
Function:
Function:
Function:
Function:
Function:
Function:
Danfoss A/S © Rev. 2014-03-31 All rights reserved.
37-55 Winder Jog Forward
Option:
Jog forward
37-56 New Diameter Select
Option:
Core diameter
*
Partial roll diameter
37-57 Tension On/Off
Option:
Off
*
On
37-58 Core Select
Option:
Core1 diameter
*
Core2 diameter
37-59 Diameter Reset
Option:
Off
*
On
Function:
Function:
Function:
Function:
Function:
