Parameter Descriptions
5-40 Function Relay
Option: Function:
time-out, the output state is set low
(off).
[56] Heat sink cleaning
warning, high
[60] Comparator 0 See parameter group 13-1* Smart
Logic Control. If Comparator 0 in SLC
is TRUE, the output goes high.
Otherwise, it goes low.
[61] Comparator 1 See parameter group 13-1* Smart
Logic Control. If Comparator 1 in SLC
is TRUE, the output goes high.
Otherwise, it goes low.
[62] Comparator 2 See parameter group 13-1* Smart
Logic Control. If Comparator 2 in SLC
is TRUE, the output goes high.
Otherwise, it goes low.
[63] Comparator 3 See parameter group 13-1* Smart
Logic Control. If Comparator 3 in SLC
is TRUE, the output goes high.
Otherwise, it goes low.
[64] Comparator 4 See parameter group 13-1* Smart
Logic Control. If Comparator 4 in SLC
is TRUE, the output goes high.
Otherwise, it goes low.
[65] Comparator 5 See parameter group 13-1* Smart
Logic Control. If Comparator 5 in SLC
is TRUE, the output goes high.
Otherwise, it goes low.
[70] Logic rule 0 See parameter group 13-4* Logic
Rules. If Logic Rule 0 in SLC is TRUE,
the output goes high. Otherwise, it
goes low.
[71] Logic rule 1 See parameter group 13-4* Logic
Rules. If Logic Rule 1 in SLC is TRUE,
the output goes high. Otherwise, it
goes low.
[72] Logic rule 2 See parameter group 13-4* Logic
Rules. If Logic Rule 2 in SLC is TRUE,
the output goes high. Otherwise, it
goes low.
[73] Logic rule 3 See parameter group 13-4* Logic
Rules. If Logic Rule 3 in SLC is TRUE,
the output goes high. Otherwise, it
goes low.
[74] Logic rule 4 See parameter group 13-4* Logic
Rules. If Logic Rule 4 in SLC is TRUE,
the output goes high. Otherwise, it
goes low.
[75] Logic rule 5 See parameter group 13-4* Logic
Rules. If Logic Rule 5 in SLC is TRUE,
MG06C402
Programming Guide
5-40 Function Relay
Option:
[80] SL digital output A See parameter 13-52 SL Controller
[81] SL digital output B
[82] SL digital output C See parameter 13-52 SL Controller
[83] SL digital output D See parameter 13-52 SL Controller
[160] No alarm
[161] Running reverse
[165] Local ref active
[166] Remote ref active
[167] Start command
activ
[168] Drive in hand
mode
[169] Drive in auto
mode
[170] Homing
Completed
[171] Target Position
Reached
[172] Position Control
Fault
[173] Position Mech
Brake
[175] Running on
tension
[176] Ready to run
[193] Sleep Mode
[194] Broken Belt
Function
5-41 On Delay, Relay
Array [9], (Relay 1 [0], Relay 2 [1], Relay 3 [2], Relay 4 [3], Relay 5
[4], Relay 6 [5], Relay 7 [6], Relay 8 [7], Relay 9 [8])
Range:
0.01 s
*
Danfoss A/S © Rev. 2014-03-31 All rights reserved.
Function:
the output goes high. Otherwise, it
goes low.
Action. Output A is low on [32] Smart
Logic Action. Output A is high on [38]
Smart Logic Action.
See parameter 13-52 SL Controller
Action. Output B is low on [32] Smart
Logic Action. Output B is high on [38]
Smart Logic Action.
Action. Output C is low on [32] Smart
Logic Action. Output C is high on [38]
Smart Logic Action.
Action. Output D is low on [32] Smart
Logic Action. Output D is high on [38]
Smart Logic Action.
Function:
[0.01 - 600 s] Enter the delay of the relay cut-in time.
The relay only cuts in if the condition in
5-40 Function Relay is uninterrupted
during the specified time.
4 4
