Parameter Descriptions
9-22 Telegram Selection
Option: Function:
[1] Standard telegram Select a standard Profibus telegram
1 configuration for the frequency
converter as an alternative to using
the freely configurable telegrams in
parameter 9-15 PCD Write Configu-
ration and parameter 9-16 PCD Read
Configuration.
[100] None
*
[101] PPO 1
[102] PPO 2
[103] PPO 3
[104] PPO 4
[105] PPO 5
[106] PPO 6
[107] PPO 7
[108] PPO 8
9-23 Parameters for Signals
Option:
[0]
*
[302] Minimum Reference
[303] Maximum Reference
[312] Catch up/slow Down Value
[341] Ramp 1 Ramp Up Time
[342] Ramp 1 Ramp Down Time
[351] Ramp 2 Ramp Up Time
[352] Ramp 2 Ramp Down Time
[380] Jog Ramp Time
[381] Quick Stop Ramp Time
[412] Motor Speed Low Limit [Hz]
[414] Motor Speed High Limit [Hz]
[416] Torque Limit Motor Mode
[417] Torque Limit Generator Mode
[553] Term. 29 High Ref./Feedb. Value
[558] Term. 33 High Ref./Feedb. Value
[590] Digital & Relay Bus Control
[593] Pulse Out 27 Bus Control
[595] Pulse Out 29 Bus Control
[615] Terminal 53 High Ref./Feedb. Value
[625] Terminal 54 High Ref./Feedb. Value
[696] Terminal 42 Output Bus Control
[748] PCD Feed Forward
[890] Bus Jog 1 Speed
[891] Bus Jog 2 Speed
[1500] Operating hours
[1501] Running Hours
[1502] kWh Counter
[1600] Control Word
[1601] Reference [Unit]
[1602] Reference [%]
[1603] Status Word
[1605] Main Actual Value [%]
MG06C402
Programming Guide
9-23 Parameters for Signals
Option:
[1609]
[1610]
[1611]
[1612]
[1613]
[1614]
[1615]
[1616]
[1618]
[1622]
[1630]
[1633]
[1634]
[1635]
[1638]
[1639]
[1650]
[1652]
Function:
[1653]
[1657]
[1660]
[1661]
[1662]
[1663]
[1664]
[1665]
[1667]
[1668]
[1669]
[1670]
[1671]
[1672]
[1673]
[1679]
[1680]
[1682]
[1684]
[1685]
[1690]
[1691]
[1692]
[1693]
[1694]
[1695]
[3401]
[3402]
[3403]
[3404]
[3405]
[3406]
[3407]
[3408]
