Parameter Lists

5.1.6 2-** Brakes

Par. No. # Parameter description
2-0* DC-Brake
2-00 DC Hold/Motor Preheat Current
2-01 DC Brake Current
2-02 DC Braking Time
2-04 DC Brake Cut In Speed
2-06 Parking Current
2-07 Parking Time
2-1* Brake Energy Funct.
2-10 Brake Function
2-11 Brake Resistor (ohm)
2-12 Brake Power Limit (kW)
2-14 Brake voltage reduce
2-16 AC Brake, Max current
2-17 Over-voltage Control
2-19 Over-voltage Gain
2-2* Mechanical Brake
2-20 Release Brake Current
2-22 Activate Brake Speed [Hz]

5.1.7 3-** Reference/Ramps

Par. No. # Parameter description
3-0* Reference Limits
3-00 Reference Range
3-01 Reference/Feedback Unit
3-02 Minimum Reference
3-03 Maximum Reference
3-04 Reference Function
3-1* References
3-10 Preset Reference
3-11 Jog Speed [Hz]
3-12 Catch up/slow Down Value
3-14 Preset Relative Reference
3-15 Reference 1 Source
3-16 Reference 2 Source
3-17 Reference 3 Source
3-18 Relative Scaling Reference Resource
3-4* Ramp 1
3-40 Ramp 1 Type
3-41 Ramp 1 Ramp Up Time
3-42 Ramp 1 Ramp Down Time
3-5* Ramp 2
3-50 Ramp 2 Type
3-51 Ramp 2 Ramp Up Time
3-52 Ramp 2 Ramp Down Time
3-6* Ramp 3
3-60 Ramp 3 Type
MG06C402
Programming Guide
Default value
50 %
50 %
10 s
0 Hz
100 %
3 s
[0] Off
ExpressionLimit
ExpressionLimit
0 V
100 %
[0] Disabled
100 %
0 A
0 Hz
Default value
[0] Min - Max
ExpressionLimit
0 ReferenceFeedbackUnit
ExpressionLimit
[0] Sum
0 %
5 Hz
0 %
0 %
[1] Analog Input 53
[2] Analog Input 54
[11] Local bus reference
[0] No function
[0] Linear
ExpressionLimit
ExpressionLimit
[0] Linear
ExpressionLimit
ExpressionLimit
[0] Linear
Danfoss A/S © Rev. 2014-03-31 All rights reserved.
2-set-up Change Conver-
during sion index
operation
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE -1
All set-ups TRUE -1
All set-ups TRUE
All set-ups TRUE -1
All set-ups FALSE
All set-ups FALSE -1
All set-ups TRUE
All set-ups FALSE
All set-ups TRUE -1
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE -2
All set-ups TRUE -1
2-set-up Change Conver-
during sion index
operation
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE
All set-ups TRUE -2
All set-ups TRUE -1
All set-ups TRUE -2
All set-ups TRUE -2
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE -2
All set-ups TRUE -2
All set-ups TRUE
All set-ups TRUE -2
All set-ups TRUE -2
All set-ups TRUE
Type
0 Uint16
0 Uint16
Uint16
Uint16
0 Uint16
5 5
Uint16
- Uint8
Uint16
0 Uint32
0 Uint16
Uint16
- Uint8
0 Uint16
Uint32
Uint16
Type
- Uint8
- Uint8
Int32
Int32
- Uint8
Int16
Uint16
Int16
Int16
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
Uint32
Uint32
- Uint8
Uint32
Uint32
- Uint8
