Parameter Descriptions
6-92 Terminal 42 Digital Output
Option:
[74] Logic rule 4
[75] Logic rule 5
[80] SL digital output A
[81] SL digital output B
[82] SL digital output C
[83] SL digital output D
4 4
[160] No alarm
[161] Running reverse
[165] Local ref active
[166] Remote ref active
[167] Start command activ
[168] Drive in hand mode
[169] Drive in auto mode
[170] Homing Completed
[171] Target Position Reached
[172] Position Control Fault
[173] Position Mech Brake
[174] TLD indicator
[175] Running on tension
[176] Ready to run
[177] End of roll
[193] Sleep Mode
[194] Broken Belt Function
[198] Drive Bypass
6-93 Terminal 42 Output Min Scale
Range:
0 % [0 - 200
*
%]
64
Programming Guide
Function:
Scale for the minimum output (0 or 4 mA) of
the analog signal at terminal 42. Set the value
to be the percentage of the full range of the
variable selected in parameter 6-91 Terminal 42
Analog Output.
Danfoss A/S © Rev. 2014-03-31 All rights reserved.
6-94 Terminal 42 Output Max Scale
Function: Range:
100 [0 -
% 200 %]
*
6-96 Terminal 42 Output Bus Control
Range:
0 [0 - 16384 ] Holds the analog output at terminal 42 if
*
6-98 Drive Type
Range:
0 [0 - 0 ]
*
Function:
Scale for maximum output (20 mA) of the scaling
at terminal 42. Set the value to be the
percentage of the full range of the variable
selected in parameter 6-91 Terminal 42 Analog
Output.
Current
(mA)
20
0/4
0% Analogue Analogue 100%
output Output
Min Scale Max Scale
par. 6-93 par. 6-94
Illustration 4.18 Output Scale vs. Current
Function:
controlled by bus.
Function:
Variable
for
output
example:
Power
