Parameter Descriptions
13-10 Comparator Operand
Option:
[0] Disabled
*
[1] Reference %
[2] Feedback %
[3] Motor speed
[4] Motor Current
[6] Motor power
4 4
[7] Motor voltage
[12] Analog input AI53
[13] Analog input AI54
[18] Pulse input FI29
[19] Pulse input FI33
[20] Alarm number
[30] Counter A
[31] Counter B
13-11 Comparator Operator
Option:
[0] Less Than (<)
[1] Approx.Equal
(~)
*
[2] Greater Than
(>)
13-12 Comparator Value
Range:
0 [-9999 -
*
9999 ]

4.12.3 13-2* Timers

Use the result (TRUE or FALSE) from timers directly to
define an event (see 13-51 SL Controller Event), or as
boolean input in a logic rule (see 13-40 Logic Rule Boolean
1, 13-42 Logic Rule Boolean 2 or 13-44 Logic Rule Boolean 3).
A timer is only FALSE when started by an action (i.e. [29]
84
Programming Guide
Function:
Function:
Select the operator to be used in the
comparison. This is an array parameter
containing comparator operators 0 to 5.
The result of the evaluation is TRUE, when
the variable selected in
parameter 13-10 Comparator Operand is
smaller than the fixed value in
parameter 13-12 Comparator Value. The
result is FALSE, if the variable selected in
parameter 13-10 Comparator Operand is
greater than the fixed value in
parameter 13-12 Comparator Value.
The result of the evaluation is TRUE, when
the variable speed selected in
parameter 13-10 Comparator Operand is
approximately equal to the fixed value in
parameter 13-12 Comparator Value.
Inverse logic of [0] Less Than (<).
Function:
Enter the "trigger level" for the variable that
is monitored by this comparator. This is an
array parameter containing comparator
values 0 to 5.
Danfoss A/S © Rev. 2014-03-31 All rights reserved.
Start timer 1) until the timer value entered in this
parameter is elapsed. Then it becomes TRUE again.
All parameters in this parameter group are array
parameters with index 0 to 2. Select index 0 to program
Timer 0, select index 1 to program Timer 1, and so on.
13-20 SL Controller Timer
Range: Function:
0 s [0 - 3600 Enter the value to define the duration of the
*
s] FALSE output from the programmed timer. A
timer is only FALSE if it is started by an action
(i.e. [29] Start timer 1 and until the given timer
value has elapsed.

4.12.4 13-4* Logic Rules

Combine up to 3 boolean inputs (TRUE/FALSE inputs) from
timers, comparators, digital inputs, status bits and events
using the logical operators AND, OR, and NOT. Select
boolean inputs for the calculation in 13-40 Logic Rule
Boolean 1, 13-42 Logic Rule Boolean 2 and 13-44 Logic Rule
Boolean 3. Define the operators used to logically combine
the selected inputs in 13-41 Logic Rule Operator 1 and
13-43 Logic Rule Operator 2.
Par. 13-41
Logic Rule Operator 1
Par. 13-40
Logic Rule Boolean 1
Par. 13-42
Logic Rule Boolean 2 . . .
. . .
Par. 13-44
Logic Rule Boolean 3
Illustration 4.24 Logic Rules
Priority of calculation
The results of 13-40 Logic Rule Boolean 1, 13-41 Logic Rule
Operator 1 and 13-42 Logic Rule Boolean 2 are calculated
first. The outcome (TRUE/FALSE) of this calculation is
combined with the settings of 13-43 Logic Rule Operator 2
and 13-44 Logic Rule Boolean 3, yielding the final result
(TRUE/FALSE) of the logic rule.
13-40 Logic Rule Boolean 1
Option: Function:
Select the first boolean (TRUE or
FALSE) input for the selected logic
rule. See parameter 13-01 Start Event
([0]-[61]) and parameter 13-02 Stop
Event ([70]-[74]) for further
description.
[0] False
*
[1] True
[2] Running
[3] In range
Par. 13-43
Logic Rule Operator 2
. . .
. . .
