5.1.3 Active/Inactive Parameters in Different Drive Control Modes

+ = active
- = not active
1-10 Motor Construction
1-01 Motor Control Principle
1-00 Configuration Mode
[0] Speed Open Loop
[1] Speed Closed Loop
[3] Process
[4] Torque Open Loop
[6] Surface Winder
[7] Ext. PID Open Loop
1-03 Torque Characteristics
1-06 Clockwise Direction
1-20 Motor Power [kW]
(Par. 023 = International)
1-22 Motor Voltage
1-23 Motor Frequency
1-24 Motor Current
1-25 Motor Nominal Speed
1-29 Automatic Motor Adaptation (AMA)
1-30 Stator Resistance (Rs)
1-33 Stator Leakage Reactance (X1)
1-34 Rotor Leakage Reactance (X2)
1-35 Main Reactance (Xh)
1-39 Motor Poles
Table 5.3 Active/inactive Parameters
1) Constant torque
2) Variable torque
3) AEO
5) Used in flystart
