Parameter Descriptions
13-52 SL Controller Action
Option:
[17] Select preset
ref 7
[18] Select ramp 1 Selects ramp 1.
4 4
[19] Select ramp 2 Selects ramp 2.
[22] Run
[23] Run reverse
[24] Stop
[25] Qstop
[26] DC Brake
[27] Coast
[28] Freeze
output
[29] Start timer 0
[30] Start timer 1
[31] Start timer 2
[32] Set digital
out A low
[33] Set digital
out B low
[34] Set digital
out C low
[35] Set digital
out D low
[38] Set digital
out A high
[39] Set digital
out B high
[40] Set digital
out C high
[41] Set digital
out D high
[60] Reset
Counter A
[61] Reset
Counter B
88
Programming Guide
Function:
Selects preset reference 7. If the active
preset reference is changed, it merges with
other preset reference commands coming
from either the digital inputs or via a
fieldbus.
Issues a start command to the frequency
converter.
Issues a start reverse command to the
frequency converter.
Issues a stop command to the frequency
converter.
Issues a quick stop command to the
frequency converter.
Issues a DC-brake command to the
frequency converter.
The frequency converter coasts immediately.
All stop commands including the coast
command stop the SLC.
Freezes the output of the frequency
converter.
See parameter 13-20 SL Controller Timer for
further description.
See parameter 13-20 SL Controller Timer for
further description.
See parameter 13-20 SL Controller Timer for
further description.
Any output with SL output A is low.
Any output with SL output B is low.
Any output with SL output C is low.
Any output with SL output D is low.
Any output with SL output A is high.
Any output with SL output B is high.
Any output with SL output C is high.
Any output with SL output D is high.
Resets Counter A to zero.
Resets Counter B to zero.
Danfoss A/S © Rev. 2014-03-31 All rights reserved.
13-52 SL Controller Action
Option: Function:
[70] Start Timer 3 See parameter 13-20 SL Controller Timer for
further description.
[71] Start Timer 4 See parameter 13-20 SL Controller Timer for
further description.
[72] Start Timer 5 See parameter 13-20 SL Controller Timer for
further description.
[73] Start Timer 6 See parameter 13-20 SL Controller Timer for
further description.
[74] Start Timer 7 See parameter 13-20 SL Controller Timer for
further description.
