Parameter Lists

5 Parameter Lists

5.1.1 Default Settings

Changes during operation
"TRUE" means that the parameter can be changed while
the frequency converter is in operation and "FALSE" means
that the frequency converter must be stopped before a
change can be made.
5 5
2-Set-up
'All set-ups': The parameter can be set individually in each
of the 2 set-ups, i. e. one single parameter can have 2
different data values.
'1 set-up': Data value is the same in all set-ups.
Data Description
type
2 Integer 8
3 Integer 16
4 Integer 32
5 Unsigned 8
6 Unsigned 16
7 Unsigned 32
9 Visible String
33 Normalized value 2 bytes
35 Bit sequence of 16 boolean variables
54 Time difference w/o date
Table 5.1 Data Type
112
Programming Guide

5.1.2 Conversion

The various attributes of each parameter are displayed in
Factory Setting. Parameter values are transferred as whole
numbers only. Conversion factors are therefore used to
transfer decimals.
4-12 Motor Speed Low Limit [Hz] has a conversion factor of
0.1. To preset the minimum frequency to 10 Hz, transfer
the value 100. A conversion factor of 0.1 means that the
value transferred is multiplied by 0.1. The value 100 is
therefore read as 10.0.
Examples:
0s ⇒ conversion index 0
Type
0.00s ⇒ conversion index -2
0ms ⇒ conversion index -3
Int8
0.00ms ⇒ conversion index -5
Int16
Int32
Uint8
Conversion index
Uint16
100
Uint32
75
VisStr
74
N2
67
V2
6
TimD
5
4
3
2
1
0
-1
-2
-3
-4
-5
-6
-7
Table 5.2 Conversion Table
Danfoss A/S © Rev. 2014-03-31 All rights reserved.
Conversion factor
1000000
100000
10000
1000
100
10
1
0.1
0.01
0.001
0.0001
0.00001
0.000001
0.0000001
MG06C402
