Parameter Descriptions
9-23 Parameters for Signals
Option:
[3409]
PCD 9 Write For Application
[3410]
PCD 10 Write For Application
[3421]
PCD 1 Read For Application
[3422]
PCD 2 Read For Application
[3423]
PCD 3 Read For Application
[3424]
PCD 4 Read For Application
4
4
[3425]
PCD 5 Read For Application
[3426]
PCD 6 Read For Application
[3427]
PCD 7 Read For Application
[3428]
PCD 8 Read For Application
[3429]
PCD 9 Read For Application
[3430]
PCD 10 Read For Application
[3450]
Actual Position
[3456]
Track Error
9-27 Parameter Edit
Option:
[0]
Disabled Disables editing via Profibus.
[1]
Enabled Enables editing via Profibus.
*
9-28 Process Control
Option:
[0]
Disable
[1]
Enable
cyclic
*
master
9-44 Fault Message Counter
Range:
0
[0 -
*
65535 ]
76
Programming Guide
Function:
Parameters can be edited via Profibus, the
standard RS-485 interface, or the LCP.
Function:
Process control (setting of Control Word, speed
reference, and process data) is possible via either
Profibus or standard fieldbus but not both
simultaneously. Local control is always possible
via the LCP. Control via process control is possible
via either terminals or fieldbus depending on the
settings in parameter 8-50 Coasting Select to
parameter 8-56 Preset Reference Select.
Disables process control via Profibus, and enables
process control via standard fieldbus or Profibus
Master class 2.
Enables process control via Profibus Master Class
1, and disables process control via standard
fieldbus or Profibus Master class 2.
Function:
Indicates the number of fault events presently
stored in parameter 9-45 Fault Code. The buffer
capacity is maximum eight error events. The
buffer and counter is set to 0 by reset or
power-up.
Danfoss A/S © Rev. 2014-03-31 All rights reserved.
9-45 Fault Code
Function:
Range:
0
[0 - 0 ] This buffer contains the alarm-word for all alarms
*
9-47 Fault Number
Range:
0
[0 - 0 ]
*
9-52 Fault Situation Counter
Range:
0
[0 - 1000 ] Indicates the number of fault events occurred
*
9-53 Profibus Warning Word
Range:
0
[0 -
*
65535 ]
9-63 Actual Baud Rate
Option:
[0]
9,6 kbit/s
[1]
19,2 kbit/s
[2]
93,75 kbit/s
[3]
187,5 kbit/s
[4]
500 kbit/s
[6]
1500 kbit/s
Function:
and warnings that have occurred since last reset or
power-up. The buffer capacity is maximum eight
error events.
Function:
Function:
since last reset or power-up.
Function:
This parameter displays Profibus communication
warnings.
Bit
Meaning
0
Connection with DP-master is lost
1
Not used
2
FDL (Fieldbus Data link Layer) is not
OK
3
Clear data command received
4
Actual value is not updated
5
Baudrate search
6
PROFIBUS ASIC is not transmitting
7
Initialising of PROFIBUS is not ok
8
Frequency converter is tripped
9
Internal CAN error
10
Wrong configuration data from PLC
11
Wrong ID sent by PLC
12
Internal error occurred
13
Not configured
14
Time-out active
15
Warning 34 active
Table 4.6 Bit Definition
Function:
This parameter displays the actual
Profibus baud rate. The Profibus
Master automatically sets the baud
rate.
MG06C402
