Parameter Lists

5.1.4 0-** Operation and Display

Par. No. # Parameter description
0-0* Basic Settings
0-01 Language
0-03 Regional Settings
0-04 Operating State at Power-up
0-06 GridType
0-07 Auto DC Braking
0-1* Set-up Operations
0-10 Active Set-up
0-11 Programming Set-up
0-12 Link Setups
0-16 Application Selection
0-2* LCP Display
0-20 Display Line 1.1 Small
0-21 Display Line 1.2 Small
0-22 Display Line 1.3 Small
0-23 Display Line 2 Large
0-24 Display Line 3 Large
0-3* LCP Custom Readout
0-30 Custom Readout Unit
0-31 Custom Readout Min Value
0-32 Custom Readout Max Value
0-37 Display Text 1
0-38 Display Text 2
0-39 Display Text 3
0-4* LCP Keypad
0-40 [Hand on] Key on LCP
0-42 [Auto on] Key on LCP
0-44 [Off/Reset] Key on LCP
0-5* Copy/Save
0-50 LCP Copy
0-51 Set-up Copy
0-6* Password
0-60 Main Menu Password

5.1.5 1-** Load and Motor

Par. No. # Parameter description
1-0* General Settings
1-00 Configuration Mode
1-01 Motor Control Principle
1-03 Torque Characteristics
1-06 Clockwise Direction
1-08 Motor Control Bandwidth
1-1* Motor Selection
1-10 Motor Construction
1-14 Damping Gain
1-15 Low Speed Filter Time Const.
MG06C402
Programming Guide
Default value
[0] English
[0] International
[0] Resume
ExpressionLimit
[1] On
[1] Set-up 1
[9] Active Set-up
[20] Linked
[0] None
1602
1614
1610
1613
1502
[1] %
0 CustomReadoutUnit
100 CustomReadoutUnit
[]
[]
[]
[1] Enabled
[1] Enabled
[1] Enabled
[0] No copy
[0] No copy
0 N/A
Default value
[0] Open Loop
+
[1] VVC
[0] Constant torque
[0] Normal
ExpressionLimit
[0] Asynchron
120 %
ExpressionLimit
Danfoss A/S © Rev. 2014-03-31 All rights reserved.
2-set-up Change Conver-
during sion index
operation
1 set-up TRUE
1 set-up FALSE
All set-ups TRUE
1 set-up FALSE
1 set-up FALSE
1 set-up TRUE
1 set-up TRUE
All set-ups FALSE
1 set-up FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
1 set-up FALSE
1 set-up FALSE
1 set-up TRUE
2-set-up Change
during
operation
All set-ups TRUE
All set-ups FALSE
All set-ups FALSE
1 set-up FALSE
1 set-up FALSE
1 set-up FALSE
All set-ups TRUE
All set-ups TRUE
Type
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
5
- Uint8
- Uint8
- Uint8
- Uint8
- Uint16
- Uint16
- Uint16
- Uint16
- Uint16
- Uint8
-2 Int32
-2 Int32
0 VisStr[21]
0 VisStr[26]
0 VisStr[26]
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
0 Uint16
Conver- Type
sion index
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
0 Int16
-2 Uint16
115
5
