Data Readouts; Application Functions; Special Features; Motion Control Basic Settings - Danfoss VLT AutomationDrive FC 360 Programming Manual

Parameter Lists

5.1.20 18-** Data Readouts 2

Par. No. # Parameter description
18-9* PID Readouts
18-90 Process PID Error
18-91 Process PID Output
18-92 Process PID Clamped Output
18-93 Process PID Gain Scaled Output
5 5

5.1.21 22-** Application Functions

Par. No. # Parameter description
22-4* Sleep Mode
22-40 Minimum Run Time
22-41 Minimum Sleep Time
22-43 Wake-Up Speed [Hz]
22-44 Wake-Up Ref./FB Diff
22-45 Setpoint Boost
22-46 Maximum Boost Time
22-47 Sleep Speed [Hz]
22-6* Broken Belt Detection
22-60 Broken Belt Function
22-61 Broken Belt Torque
22-62 Broken Belt Delay

5.1.22 30-** Special Features

Par. No. # Parameter description
30-2* Adv. Start Adjust
30-20 High Starting Torque Time [s]
30-21 High Starting Torque Current [%]
30-22 Locked Rotor Protection
30-23 Locked Rotor Detection Time [s]

5.1.23 32-** Motion Control Basic Settings

Par. No. # Parameter description
32-11 User Unit Denominator
32-12 User Unit Numerator
32-67 Max. Tolerated Position Error
32-69 PID Sample Time
32-80 Maximum Allowed Velocity
32-81 Motion Ctrl Quick Stop Ramp
128
Programming Guide
Default value
0 %
0 %
0 %
0 %
Default value
10 s
10 s
10 N/A
10 %
0 %
60 s
0 N/A
[0] Off
10 %
10 s
Default value
ExpressionLimit
ExpressionLimit
[0] Off
0.10 s
Default value
1 N/A
1 N/A
2000000 N/A
16 ms
1500 RPM
1000 ms
Danfoss A/S © Rev. 2014-03-31 All rights reserved.
2-set-up Change Conver-
during sion index
operation
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
2-set-up Change
during
operation
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
2-set-up Change
during
operation
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
2-set-up Change
during
operation
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up FALSE
1 set-up TRUE
Type Type
-1 Int16
-1 Int16
-1 Int16
-1 Int16
Conver- Type
sion index
0 Uint16
0 Uint16
-1 Uint16
0 Uint8
0 Int8
0 Uint16
-1 Uint16
- Uint8
0 Uint8
0 Uint16
Conver- Type
sion index
-2 Uint16
-1 Uint32
- Uint8
-2 Uint8
Conver- Type
sion index
0 Uint32
0 Uint32
0 Uint32
-3 Uint16
67 Uint16
-3 Uint32
MG06C402
