Parameter Descriptions
13-51 SL Controller Event
Option: Function:
Operator 1 and parameter 13-42 Logic
Rule Boolean 2, and the boolean
input. See parameter 13-01 Start Event
([0]-[61]) and parameter 13-02 Stop
Event ([70]-[74]) for further
description.
[0] False
*
[1] True
[2] Running
[3] In range
[4] On reference
[7] Out of current range
[8] Below I low
[9] Above I high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[39] Start command
[40] Drive stopped
[42] Auto Reset Trip
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[83] Broken Belt
MG06C402
Programming Guide
13-52 SL Controller Action
Option:
[0] Disabled
*
[1] No action
[2] Select set-up
1
[3] Select set-up
2
[10] Select preset
ref 0
[11] Select preset
ref 1
[12] Select preset
ref 2
[13] Select preset
ref 3
[14] Select preset
ref 4
[15] Select preset
ref 5
[16] Select preset
ref 6
Danfoss A/S © Rev. 2014-03-31 All rights reserved.
Function:
Select the action corresponding to the SLC
event. Actions are executed when the
corresponding event (defined in
parameter 13-51 SL Controller Event) is
evaluated as true.
Changes the active set-up
(parameter 0-10 Active Set-up) to '1'. If the
set-up is changed, it merges with other set-
up commands coming from either the
digital inputs or via a fieldbus.
Changes the active set-up
(parameter 0-10 Active Set-up) to '2'. If the
set-up is changed, it merges with other set-
up commands coming from wither the
digital inputs or via a fieldbus.
Select preset reference 0. If the active preset
reference is changed, it merges with other
preset reference commands coming from
either the digital inputs or via a fieldbus.
Selects preset reference 1. If the active
preset reference is changed, it merges with
other preset reference commands coming
from either the digital inputs or via a
fieldbus.
Selects preset reference 2. If the active
preset reference is changed, it merges with
other preset reference commands coming
from either the digital inputs or via a
fieldbus.
Selects preset reference 3. If the active
preset reference is changed, it merges with
other preset reference commands coming
from either the digital inputs or via a
fieldbus.
Selects preset reference 4. If the active
preset reference is changed, it merges with
other preset reference commands coming
from either the digital inputs or via a
fieldbus.
Selects preset reference 5. If the active
preset reference is changed, it merges with
other preset reference commands coming
from either the digital inputs or via a
fieldbus.
Selects preset reference 6. If the active
preset reference is changed, it merges with
other preset reference commands coming
from either the digital inputs or via a
fieldbus.
4 4
