Parameter Descriptions

4.4 Parameters: 3-** Reference/Ramps

4.4.1 3-0* Reference Limits

Parameters for setting the reference unit, limits and ranges.
3-00 Reference Range
Option:
[0] Min - Max
*
4 4
[1] -Max - +Max For both positive and negative values (both
3-01 Reference/Feedback Unit
Option:
[0]
[1]
[2]
[3]
[4]
[5]
[10]
[12]
[20]
[21]
[22]
[23]
[24]
[25]
[30]
[31]
[32]
[33]
[34]
[40]
[41]
[45]
[60]
[70]
[71]
[72]
[73]
[74]
[80]
[120]
[121]
[122]
[123]
[124]
[125]
[126]
[127]
[130]
40
Programming Guide
Function:
Select the range of the reference signal and
the feedback signal. Signal values can be
positive only, or positive and negative.
directions), relative to 4-10 Motor Speed
Direction.
Function:
None
%
RPM
Hz
Nm
PPM
1/min
Pulse/s
l/s
l/min
l/h
m³/s
m³/min
m³/h
kg/s
kg/min
kg/h
t/min
t/h
m/s
m/min
m
°C
mbar
bar
Pa
kPa
m WG
kW
GPM
gal/s
gal/min
gal/h
CFM
ft³/s
ft³/min
ft³/h
lb/s
Danfoss A/S © Rev. 2014-03-31 All rights reserved.
3-01 Reference/Feedback Unit
Option:
[131] lb/min
[132] lb/h
[140] ft/s
[141] ft/min
[145] ft
[150] lb ft
[160] °F
[170] psi
[171] lb/in2
[172] in WG
[173] ft WG
[180] HP
3-02 Minimum Reference
Range:
0 Reference- [ 0 - 4999
FeedbackUnit ReferenceFeed-
*
backUnit]
3-03 Maximum Reference
Range: Function:
Size [-4999.0 - 4999 Enter the maximum reference. The
related ReferenceFeed- maximum reference is the highest
*
backUnit] value obtainable by summing all
references.
The maximum reference unit
matches:
•
•
Function:
Function:
Enter the minimum reference. The
minimum reference is the lowest
value obtainable by summing all
references.
Minimum reference is active only
when parameter 3-00 Reference
Range is set to [0] Min.- Max.
The minimum reference unit
matches:
•
The choice of configu-
ration in
parameter 1-00 Configu-
ration Mode
•
The unit selected in
parameter 3-01 Reference/
Feedback Unit
The choice of configuration
in parameter 1-00 Configu-
ration Mode
The unit selected in
parameter 3-00 Reference
Range
