CDM-750 Advanced High-Speed Trunking Modem
Ethernet-based Remote Product Management
6.5.4.3
Configuration pages
Use these pages to configure all unit parameters. Click the Configuration navigation tab, and
then select the Modem, Utilities, Test, or LNB page tab to continue.
6.5.4.3.1
Configuration | Modem
The Tx / Rx Interface Types and Framing Modes have higher priority than other
parameters, and should be configured before setting other parameters.
See Chapter 5. FRONT PANEL OPERATION for details pertaining to configuration
parameters available on this page:
Web Page Section
Transmit
Receive
ACM
Carrier-in-Carrier (CnC)
Once the desired configuration settings have been made in each section, click [Submit] to save
the settings for that section.
Chapter 5 Section Reference
5.2.2.2 CONFIG: Tx
5.2.2.3 CONFIG: Rx
• 5.2.2.5 CONFIG: ACM
• Appendix C. ADAPTIVE CODING and MODULATION (ACM) OPTION
• 5.2.2.6 CONFIG: CnC
• Appendix D. D
Figure 6-5. Configuration | Modem page
6–15
T
C
-
-C
OUBLE
ALK
ARRIER
IN
ARRIER
Revision 2
MN-CDM750
OPTION
