CDM-750 Advanced High-Speed Trunking Modem
Serial-based Remote Product Management
Command
Parameter Number of
(Instruction
Type Arguments
& Qualifier)
Management IPG= 15 bytes
Default numerical
IP Gateway
Management N/A 12 bytes,
MAC Address alpha-
numerical
GE1 Link LC1= 1 byte, value
Configuration of 0 thru 6
GE2 Link LC2= 1 byte, value
Configuration of 0 thru 6
Gig Optical LC3= 1 byte, value
Ethernet of 0 or 1
Interface
Inband SLC= 1 byte, value
Communi- of 0 or 1
cations
Description of Arguments
Command or Query.
Set or return the IP Gateway Address for the Ethernet management port in the form aaa.bbb.ccc.ddd where:
aaa = 000-223
bbb = 000-255
ccc = 000-255
ddd = 001-255
Example: IPG=010.006.030.001.24
Query only.
Return the unique MAC Address for the modem in the form aabbccddeeff.
Example: MAC=0006B00001C2
Command or Query.
Set or return the GE1 Interface mode in the form x, where:
0 = Auto Negotiate (default)
1 = 1000Mbps Full Duplex
2 = 100Mbps Full Duplex
3 = 100Mbps Half Duplex
4 = 10Mbps Full Duplex
5 = 10Mbps Half Duplex
6 = Off
Command or Query.
Set or return the GE2 Interface mode in the form x, where:
0 = Auto Negotiate (default)
1 = 1000Mbps Full Duplex
2 = 100Mbps Full Duplex
3 = 100Mbps Half Duplex
4 = 10Mbps Full Duplex
5 = 10Mbps Half Duplex
6 = Off
Command or Query.
GigE Optical Ethernet Interface mode, where x may be:
0 = Off
1 = On
NOTE: Option must be purchased and SFP module installed!
Command or Query.
Set or return isolation (opening) or connection of the SERDES link between the management Ethernet port and
the data Ethernet ports, in the form x, where:
0 = Inband Disabled
1 = Inband Enabled
7–22
Revision 2
MN-CDM750
Query
Response to
(Instruction & Response to Query
Command
Qualifier)
IPG= IPG? IPG=xxx.xxx.xxx.xxx
IPG? (see Description of
IPG* Arguments)
IPG#
N/A MAC? MAC=aabbccddeeff
(see Description of
Arguments)
LC1= LC1? LC1=x
LC1? (see Description of
LC1* Arguments)
LC1#
LC2= LC2? LC2=x
LC2? (see Description of
LC2* Arguments)
LC2#
LC3= LC3? LC3=x
LC3? (see descriptor
LC3* arguments)
LC3#
SLC= SLC? SLC=x
SLC? (see Description of
SLC* Arguments)
SLC#
