CDM-750 Advanced High-Speed Trunking Modem
Serial-based Remote Product Management
7.5.7

PIIC Interface Parameters

Command
Parameter Number of
(Instruction
Type Arguments
& Qualifier)
Rx Interface RCK= 2 bytes
Clock source
Tx Interface TCK= 2 bytes
Clock source
Interface EFI= 2 bytes
Reference
Clock
Description of Arguments
Command or Query.
Set or return Rx Clock Source (For Data Rate Accuracy) in the form sx, where:
s = Defines which Interface Slot (1 or 2)
x = Rx Clock Source, where:
0 = Tx Clock
1 = External Clock (not valid for OC3 interface)
2 = Rx Sat
3 = Internal Clock
NOTE: In MultiStream Mode, RCK is forced to internal clock.
Example: RCK=12 ( Slot 1, Rx Sat Clock is selected)
Command or Query.
Set or return Tx Clock Source (For Data Rate Accuracy), where:
s = Defines which Interface Slot (1 or 2)
x = Rx Clock Source, where:
0 =Tx Clock
1 = External Clock (not valid for OC3 interface)
2 = Rx Sat
Example: TCK=10 ( Slot 1, Tx Clock is selected)
Command or Query.
(G.703 interface only) Set or return External Clock (Interface) in the form sx, where:
s = Defines which Interface Slot (1 or 2)
x = EXT CLK (Data Rate Accuracy), where:
0 = 1 MHz
1 = 2 MHz
2 = 5 MHz
3 = 10 MHz
4 = 20 MHz
5 = 34.368 MHz
6 = 44.736 MHz
7 = 51.840 MHz
NOTE: For selections 5-7, the PIIC must be set to the corresponding interface type – i.e., 5 is valid when PIIC is
in E3 mode, 6 is valid when PIIC is in T3 mode, and 7 is valid when PIIC is in STS1 mode.
Example: EFI=14 (Selects 10MHz on Slot 1)
7–27
Revision 2
MN-CDM750
Query
Response to
(Instruction & Response to Query
Command
Qualifier)
RCK = RCK?s RCK=sx
RCK? (see Description of
RCK * Arguments)
RCK #
TCK = TCK?s TCK=sx
TCK? (see Description of
TCK * Arguments)
TCK #
EFI = EFI?s EFI=sx
EFI? (see Description of
EFI * Arguments)
EFI #
