CDM-750 Advanced High-Speed Trunking Modem
Installation
Tools needed to install the KT‐0000168 (4") or KT‐0000195 (10") Bracket Kit (Figure 2‐3):
•
A medium Phillips™ screwdriver
•
A 5/32‐inch SAE Allen™ Wrench
•
An adjustable Crescent™ wrench.
Follow these steps to install the Radyne‐style chassis kit:
Step Description
Assemble the Adapter Plates to the back side of the CDM‐750 chassis using the #10
1
Flat Head Screws.
Assemble the #10 Shoulder Screws through the Adapter Plate mounting slots using
2
the #10 Flat Washers, #10 Split Washers, and #10 Hex Nuts.
Mount the Rear Support Brackets to the rack enclosure threaded rear mounting
3
rails using the #10 Rack Bracket Bolts.
Slide the CDM‐750 into the front of the rack enclosure. Make sure that the #10
4
Shoulder Screws properly engage into the slots of the Rear Support Brackets.
