CDM-750 Advanced High-Speed Trunking Modem
Appendix D
At the station transmitting C1:
CnC Ratio (in dB) = PowerC1 (in dBm) – PowerC2 (in dBm)
Eb/No
Ratio of Energy per bit (Eb) to Noise density (No) (unit in dB):
Eb/No = C/No – 10log(DR) (where DR is the Data Rate)
Eb/No = Es/No – 10log(SE) (where SE is Spectral Efficiency)
Es/No
Ratio of Energy per symbol (Es) to Noise density (No) (unit in dB):
Es/No = C/No – 10log(SR) (where SR is the Symbol Rate)
Es/No = Eb/No + 10log(SE) (where SE is Spectral Efficiency)
C/N
Ratio of Carrier Power (C) to Noise (N) (unit in dB):
Equivalent to Es/No when calculated in the Symbol Rate
bandwidth.
C/No
Ratio of Carrier Power (C) to Noise Density (N
Co+No/No
Ratio of Carrier Density (C
– 10log(B) [where B is bandwidth in Hz]
C/N = C/N
o
E /N = C/N – 10log(DR) [where DR is data rate in bits/sec]
b o o
= C/N + 10log(B) – 10log(DR)
= C/N – 10log(SE) (where SE is Spectral Efficiency)
E /N = 10log (10
b o
[Note: Spectral Efficiency is in bps / Hz]
) + Noise (N
o
((Co+No/No)/10)
– 1) – 10log(SE) (where SE is Spectral Efficiency)
) (unit in dBHz)
o
) to Noise Density (N
o
D–22
MN-CDM750
) (unit in dB):
o
Revision 2
