1.4.11 Optional Assemblies

Assembly Description
PL-0000572 Carrier-in-Carrier Card
PL-0000635 K4 GZip Lossless Compression Card
KT-0000168 Rear-Mounting Support Bracket (4")
KT-0000195 Rear-Mounting Support Bracket (10")
FP/SL0006 Bearingless Side Railings
IC-0000058 SFP Optical Gigabit Ethernet Data Interface
PL-0000795 G.703 'BNC' E3/T3/STS-1 PIIC Module
KT-0000255 SFP STM-1 Copper 'BNC' PIIC Module
KT-0000256 SFP OC-3 Single Mode PIIC Module
KT-0000257 SFP OC-3 Multi Mode PIIC Module
Where Installed
In chassis (top cover access), modem card plug-in
In chassis (top cover access), modem card plug-in
At rear sides of chassis, and rack rear mounting
rails
At rear sides of chassis, and rack rear mounting
rails
On sides of chassis
Rear Panel J7 | Optical port
Real Panel PIIC Slots 1 and 2
Real Panel PIIC Slots 1 and 2
Real Panel PIIC Slots 1 and 2
Real Panel PIIC Slots 1 and 2
1–16
Revision 2
MN-CDM750
Chapter
Sect.
N/A
N/A
2.2.1
2.2.1
2.2.2
3.2.3.2
B.2.1
B2.2
B.2.3
