CDM-750 Advanced High-Speed Trunking Modem
Appendix C
followed by a deep fade of 6.9 dB that throttles throughput down to 31 Mbps. Table C‐3
summarizes the capacity.
Parameter
Data Rate
ModCod
Figure C-2. User Throughput vs. Time and Fades

Table C-3. Turning Margin into Additional Capacity

SLA
25 Mbps
QPSK 3/5
Clear 2.2 dB Fade
64 Mbps 51 Mbps
16-APSK 5/6 16-APSK 2/3
C–5
Revision 2
MN-CDM750
6.9 dB Fade
31 Mbps
QPSK 4/5
