megabit data rates where latency effects are minimal. The standard block size for LDPC is 64,800
bits and, for lower data rate applications, a short frame block at 16,800 bits suffers only a small
error correcting loss (0.2 to 0.5 dB) compared to the standard block.
H.2.1 Range of Data Rates
See Sect. 1.4 SUMMARY OF SPECIFICATIONS for the range of available data rates.
H.2.2 BER, QEF, Eb/No, Es/No Spectral Efficiency, and Occupied Bandwidth
Depending on the operating mode, the DVB standard uses different modes of specifying
performance with a unit in IF Loop and Additive White Gaussian Noise (AWGN):
•
DVB‐S (QPSK with Viterbi and Reed Solomon): BER = 2x10
Solomon) and QEF after Reed Solomon at the specified Eb/No and includes a modem
implementation loss of 0.8 dB and the noise bandwidth increase due to the outer code
(10 188/204 = 0,36 dB).
log
•
DVB‐S2 standard: "Quasi Error Free" (QEF) is defined as "less than one uncorrected
error‐event per transmission hour at the level of a 5 Mbits/s single TV service decoder",
approximately corresponding to a Transport Stream Packet Error Ratio equal to a
PER<10
size data.
•
Es/No vs. Eb/No: The DVB‐S2 standard commonly refers to the use of Es/No instead of
Eb/No. When links operate at a constant symbol rate this is a good method for comparing
the performance of different modulation types and code rates.
The relation between the two quantities is given by:
•
Occupied Bandwidth: Occupied bandwidth is defined as the bandwidth between ‐10 dB
points of the power spectral density, which are approximately:
Occupied Bandwidth
* Taken at the -10 dB points on the plot of power spectral density, the occupied bandwidth is 1.19 x Symbol Rate for
35%, and 1.15 x Symbol Rate for 25%.
Figure H‐1 through Figure H‐4 illustrate the guaranteed error performance characteristics of the
CDM‐750 while running with Normal frames (64,800 bits), Pilots ON. QPSK 1/4, 1/3, 2/5 are
shown for information only and are not available in the CDM‐750.
‐7
before demultiplexer. A packet is defined as block of 188‐byte MPEG frame
Eb/No = Es/No – 10
= 1.19
= 1.15
= 1.12 x Symbol Rate, for 20% Rolloff
(Spectral Efficiency)
log
Symbol Rate, for 35% Rolloff
x
Symbol Rate, for 25% Rolloff
x
H–2
Revision 2
MN-CDM750
‐4
after Viterbi (before Reed
