CDM-750 Advanced High-Speed Trunking Modem
Ethernet-based Remote Product Management
6.5.4.5.1

Interfaces | Ethernet

GBEI Common
Sect. 5.2.2.1.4 (CONFIG:) INTF: GBEIX Flow Control or Learning
Use the drop‐down lists to select Flow Control or Learning as Enabled or Disabled.
Click [Submit] to save these settings.
GBEI Interfaces (Disable PIIC Interfaces Before Configuring Ethernet Ports)
Sect. 5.2.2.1.1 Single Stream Mode vs. MultiStream Mode Operation
Use the drop‐down lists to select the appropriate mode of operation or the GBEI 1, GBEI 2, or
when installed, the optional Optical Ethernet SFP Module.
Click [Submit] to save these settings.
Tx Data Rates (Read Only)
Sect. 5.2.2.2.6 (CONFIG:) Tx: Data Tx Data Rate
Figure 6-16. Interfaces | Ethernet page
6–27
Revision 2
MN-CDM750
