CDM-750 Advanced High-Speed Trunking Modem
Serial-based Remote Product Management
Command
Parameter Number of
(Instruction
Type Arguments
& Qualifier)
GBEI Flow GFC= 1 byte, value
Control of 0 or 1
GBEI MAC LRN= 1 byte, value
Learning of 0 or 1
SNMP Read SRC= 16 bytes,
Community characters, no
spaces
SNMP SWC= 16bytes,
Write characters, no
Community spaces
SNMP Trap STA= 15 bytes,
Destination IP Numerical
Address 1
SNMP Trap STB= 15 bytes,
Destination IP Numerical
Address 2
SNMP SSC= 255 bytes,
System characters,
Contact
SNMP SSN= 16 bytes,
Unit Name characters,
Description of Arguments
Command or Query.
Enable or disable flow control (applies to all ports) in the form x, where:
0 = Disable GBEI Flow Control
1 = Enable GBEI Flow Control
Command or Query.
Enable or disable MAC address learning (applies to all ports) in the form x, where:
0 = Disable MAC learning
1 = Enable MAC learning
Command or Query.
Set or return SNMP read community string. Empty string is not allowed
Example: <1/SRC=public
Command or Query.
Set or return SNMP write community string. Empty string is not allowed
Example: <1/SWC=private
Command or Query.
Set or return the IP address of the first SNMP Trap destination IP Address 1 where traps will be sent, in the form
xxx.xxx.xxx.xxx (the IP address).
Example: <1/STA=010.006.030.001
Returns >0001/STA=0.0.0.0 when not configured.
Command or Query.
Set or return the IP address of the SNMP Trap destination IP Address 2 where traps will be sent, in the form
xxx.xxx.xxx.xxx (the IP address).
Example: <1/STB=010.006.030.001
Returns >0001/STB=0.0.0.0 When not configured.
Command or Query.
Set or return SNMP System Contact string.
Example: <1/SSC=Joe Net Admin
If not configured it returns empty string: <1/SSC=
Command or Query.
Set or return SNMP System Name string.
Example: <1/SSN=Remote1
If not configured it returns empty string: <1/SSC=
7–23
Revision 2
MN-CDM750
Query
Response to
(Instruction & Response to Query
Command
Qualifier)
GFC= GFC? GFC=x (see
GFC* Description of
GFC# Arguments)
LRN= LRN? LRN=x (see
LRN? Description of
Arguments)
SRC = SRC? SRC =x
SRC! (see description of
arguments)
SWC = SWC? SWC =x
SWC! (see description of
arguments)
STA = STA? STA =
STA! xxx.xxx.xxx.xxx
(see description of
arguments)
STB = STB? STB =
STB! xxx.xxx.xxx.xxx
(see description of
arguments)
SSC = SSC? SSC =x [1..128]
SSC! (see description of
arguments)
SSN = SSN? SSN =x [1..128]
SSN! (see description of
arguments)
