Comtech EF Data CDM-750 Installation And Operation Manual page 219

CDM-750 Advanced High-Speed Trunking Modem
Serial-based Remote Product Management
Command
Parameter Number of
(Instruction
Type Arguments
& Qualifier)
BERT Pattern N/A 1 byte, value
Sync of 1 or 2
Tx Baseband N/A
Frames per
Modcod
Rx Baseband N/A
Frames per
Modcod
Rx Baseband N/A
Frames
received with
errors per
Modcod
Rx Baseband N/A
Frames
discarded
Description of Arguments
Query only.
Returns the BER Test Pattern Sync Status in the form x, where:
1 = pattern sync
2 = no pattern sync
Query only.
Return format for each modcod entry is x.xE+xx with each entry separated by a colon. There are 25 total entries
beginning with modcod 4 (QPSK 1/2 ) and ending with modcod 28 (32APSK 9/10).
Query only.
Return format for each modcod entry is x.xE+xx with each entry separated by a colon. There are 25 total entries
beginning with modcod 4 (QPSK 1/2 ) and ending with modcod 28 (32APSK 9/10).
Query only.
Return format for each modcod entry is x.xE+xx with each entry separated by a colon. There are 25 total entries
beginning with modcod 4 (QPSK 1/2 ) and ending with modcod 28 (32APSK 9/10).
Query only.
These are baseband frames that are received without errors but are discarded due to the required feature code
not having been purchased. Currently there are two entries separated by a colon. The first entry is for 16 APSK
frames discarded and the second is for 32 APSK frames discarded.
7–41
Revision 2
MN-CDM750
Query
Response to
(Instruction & Response to Query
Command
Qualifier)
N/A RPS? RPS=X
N/A ST2? ST2=(see
Description of
Arguments)
N/A ST3? ST3=(see
Description of
Arguments)
N/A ST4? ST4=(see
Description of
Arguments)
N/A ST5? ST5=(see
Description of
Arguments)
