CDM-750 Advanced High-Speed Trunking Modem
Installation
This equipment contains parts and assemblies sensitive to damage by Electrostatic
Discharge (ESD). Use ESD precautionary procedures when handling the equipment.
Once opened, inspect the shipment (Figure 2‐1):
Step
Task
1
Keep all shipping materials for storage or reshipment.
2
Check the packing list to ensure the shipment is complete.
Inspect the equipment for any possible damage incurred during shipment. Contact
3
the carrier and Comtech EF Data immediately to submit a damage report if damage is
evident.
4
5
2.2
Installing into a Rack Enclosure
When mounting the CDM‐750 into a rack enclosure (Figure 2‐2):
•
PROPER GROUNDING PROTECTION IS REQUIRED. The equipment must be
connected to the protective earth connection at all times. It is therefore imperative
that the unit is properly grounded, using the ground stud provided on the unit rear
panel, during installation, configuration, and operation.
•
PROPER AIR VENTILATION IS REQUIRED. In a rack system where there is high
heat discharge, provide forced‐air cooling with top‐ or bottom‐mounted fans or
blowers.
For information about custom rack enclosures, contact Comtech EF Data
Customer Support during normal business hours or visit Comtech EF Data's Web
site (www.comtechefdata.com/support.asp).
Review this CDM‐750 Advanced High‐Speed Trunking Modem Installation
and Operation Manual carefully to become familiar with operation.
Proceed to Sect. 2.2 Installation into a Rack Enclosure.
o Make sure there is adequate clearance inside the enclosure, especially at
the side for air ventilation.
o Air temperature inside the rack enclosure should never exceed 50
°
(122
F).
2–2
Revision 2
MN-CDM750
°
C
