Comtech EF Data CDM-750 Installation And Operation Manual page 218

CDM-750 Advanced High-Speed Trunking Modem
Serial-based Remote Product Management
Command
Parameter Number of
(Instruction
Type Arguments
& Qualifier)
Rx BERT RBP= 1 byte, value
Pattern of 0 thru 6
Tx BERT TBP= 1 byte, value
Pattern of 0 thru 6
BERT Error BKE= None
Insert
BERT Clear BRM= None
BER Counters
BERT Results N/A 22 bytes
All: Total Bit
Errors, Total
Number Of
Bits and
average BER
Tx BERT BTX= 1 byte, value
State of 0 or 1
Description of Arguments
Command or Query.
Set or return the PN loopback pattern type in the form x, where:
0 = 2^23-1
1 = Reserved
2 = Reserved
3 = Reserved
4 = Reserved
5 = 2047
6 = 2^15-1
Example: RBP=0 (default 2^23-1)
Command or Query.
Initialises the PN loopback functionality and sets the pattern type in the form x, where:
0 = 2^23-1
1 = Reserved
2 = Reserved
3 = Reserved
4 = Reserved
5 = 2047
6 = 2^15-1
Example: TBP=0 (default 2^23-1)
Command only.
Inserts a single error.
Command only
Clears the BER counters.
Query only.
Returns 3 values, with each parameter is separated by a colon, in the form x.xEx:y.yEy:z.zEz where:
x.xEx = total number of bit errors
yEy = total number of bits
z.zEz = value of the average BER or "No Sync" if no demod lock.
Example 1: BRA=1.0E+03:2.2E+06:1.0E+03 (No Demod Lock)
Example 2: BRA=1.0E+03:2.2E+06 (No Sync)
Command or Query.
Set or return Tx BERT state in the form of x, where:
0 = off
1 = on
Example: BTX=1 (BERT On)
7–40
Revision 2
MN-CDM750
Query
Response to
(Instruction & Response to Query
Command
Qualifier)
RBP = RBP? RBP =
RBP? (see Description of
RBP * Arguments)
RBP #
TBP = TBP? TBP =
TBP? (see Description of
TBP * Arguments)
TBP #
BKE = N/A N/A
BKE?
BKE #
BRM = N/A N/A
BRM?
BRM *
BRM #
N/A BRA? BRA=x.xEx:y.yEy:z.z
Ez
(see Description of
Arguments)
BTX = BTX? BTX =x
BTX? (see Description of
BTX * Arguments)
BTX #
