Connecting the Hardware

Choosing a Location

The Cisco IEC 4600 Series is intended for indoor use only. The Cisco IEC 4600 Series must be located
within eight feet of an electrical outlet for the power adapter to reach the outlet.

Mounting the Hardware

The Cisco IEC 4600 Series comes with an optional mounting bracket, which makes mounting the unit
to a monitor with a VESA mount or various other surfaces (walls, desks, etc.) easy.
Since Cisco IEC 4600 Series is designed for convectional cooling, vertical mounting is highly
Tip
recommended.
If you want to use a remote control and you will not use an IR extender as is recommended, the infrared
Note
(IR) must be in sight of the user. Hence you will need to determine an alternative mounting to that which
is recommended here.
Step 1 Locate a vertical surface near the video display where you want the IEC 4600 Series to be mounted.
Step 2 Attach the mounting place to the video display, wall, or kiosk. Mount so that the up arrow points upwards
and is visible.
Note If mounting to sheet rock or other porous surface, use appropriate mounting hardware (not supplied).
Figure 2-1
