Appendix G Stream Live Video
The Document Camera is composed of two units: the camera itself mounted to the ceiling and the Vaddio
Quick-Connect HD-18 DVI/HDMI, which delivers simultaneous analog component video (YPbPr) and
digital video (DVI-D or HDMI) outputs on separate connectors, up to 100 feet over a single Cat. 5 cable.
There is no API for the Vaddio document camera. Instead a hex string is sent via RS232 to the camera
using the serialPorts API. For example:
Stream Live Video
To stream live video, the following components are required:
1.
2.
3.
4.
Connect Hardware
Follow these steps to connect the camera, Quick-Connect, and encoder dongle to the IEC:
Table G-1
Rotary Switch Setting
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
Camera ON: \x81\x01\x04\x00\x02\xFF
Camera OFF: \x81\x01\x04\x00\x03\xFF
Vaddio CeilingVIEW HD-18 DocCAM
Vaddio Quick-Connect HD-18 DVI/HDMI
System Dimensions AVS 2610 encoder dongle
USB extension cable
Vaddio HD Camera Resolutions
HD Camera Resolution
720p/59.94
1080i/59.94
1080p/59.94
1080p/60
720p/50
1080i/50
1080p/50
1080p/30
1080p/25
1024 x 768/60 RGBHV
1280 x 800/60 RGBHV
1680 x 1050/60 RGBHV
