Hard Brake Lines - Factory Five Racing MK4 ROADSTER Assembly Manual

Push the brake line adapters through the brackets from the outside in and install the clips that hold them
in place.
If removed, attach the front brake line to the caliper making sure there is a crush-washer on either side of
the fitting. Hand tight is fine on all these for now.

Hard brake lines

From the bottom of the master cylinder, run the 20" brake line forward to the left front brakes.
Using the distribution block diagram below, attach the other 60" brake line to the distribution block.
Brake Line Routing at Distribution Block
From Master Cylinder Rear
From Master Cylinder Front side
Firewall
Front of Car
To Right
Front Brakes
To Rear Brakes
Brake distribution block line routing. Right is towards front of car.
212
