Appendix B - Settings and Signals
ORDINAL
1699 IEC Usr 02 Close
IEC61850 User Dual Point Status 2 Closed
1700 IEC Usr 03 Open
IEC61850 User Dual Point Status 3 Open
1701 IEC Usr 03 Close
IEC61850 User Dual Point Status 3 Closed
1702 IEC Usr 04 Open
IEC61850 User Dual Point Status 4 Open
1703 IEC Usr 04 Close
IEC61850 User Dual Point Status 4 Closed
1704 IEC Usr 05 Open
IEC61850 User Dual Point Status 5 Opened
1705 IEC Usr 05 Close
IEC61850 User Dual Point Status 5 Closed
1706 IEC Usr 06 Open
IEC61850 User Dual Point Status 6 Open
1707 IEC Usr 06 Close
IEC61850 User Dual Point Status 6 Closed
1708 IEC Usr 07 Open
IEC61850 User Dual Point Status 7 Open
1709 IEC Usr 07 Close
IEC61850 User Dual Point Status 7 Closed
1710 IEC Usr 08 Open
IEC61850 User Dual Point Status 8 Open
1711 IEC Usr 08 Close
IEC61850 User Dual Point Status 8 Closed
1712 Prop Dly Change
Indicates a comms channel propagation change
1713 Cdiff CTS Ind
Cdiff CTS indicates a CTS condition
1714 Cdiff CTS Block
Cdiff CTS blocks a CTS condition
1720 Intlock CB1 CLS
CB1 close enabled (interlock)
1721 Intlock CB1 OPN
CB1 open enabled (interlock)
1724 Inhibit ISEF>1
Inhibit stage 1 SEF
1725 Inhibit ISEF>2
Inhibit stage 2 SEF
1726 Inhibit ISEF>3
Inhibit stage 3 SEF
1727 Inhibit ISEF>4
Inhibit stage 4SEF
1728 Quality VIP 1
GOOSE virtual input 1 - provides the Quality attributes of any data object in an incoming GOOSE message
1729 Quality VIP 2
GOOSE virtual input 2 - provides the Quality attributes of any data object in an incoming GOOSE message
1730 Quality VIP 3
GOOSE virtual input 3 - provides the Quality attributes of any data object in an incoming GOOSE message
1731 Quality VIP 4
GOOSE virtual input 4 - provides the Quality attributes of any data object in an incoming GOOSE message
1732 Quality VIP 5
GOOSE virtual input 5 - provides the Quality attributes of any data object in an incoming GOOSE message
1733 Quality VIP 6
GOOSE virtual input 6 - provides the Quality attributes of any data object in an incoming GOOSE message
1734 Quality VIP 7
GOOSE virtual input 7 - provides the Quality attributes of any data object in an incoming GOOSE message
B264
SIGNAL NAME
DDB_IEC_USR_CLS_2
DDB_IEC_USR_OPN_3
DDB_IEC_USR_CLS_3
DDB_IEC_USR_OPN_4
DDB_IEC_USR_CLS_4
DDB_IEC_USR_OPN_5
DDB_IEC_USR_CLS_5
DDB_IEC_USR_OPN_6
DDB_IEC_USR_CLS_6
DDB_IEC_USR_OPN_7
DDB_IEC_USR_CLS_7
DDB_IEC_USR_OPN_8
DDB_IEC_USR_CLS_8
DDB_PROP_DELAY_CHANGE
DDB_CDIFF_CTS_INDICATION
DDB_CDIFF_CTS_BLOCK
DDB_INTERLOCK_CB1_CLS_ENABLED
DDB_INTERLOCK_CB1_OPN_ENABLED
DDB_INHIBIT_SEF1
DDB_INHIBIT_SEF2
DDB_INHIBIT_SEF3
DDB_INHIBIT_SEF4
DDB_VIP_QUALITY_1
DDB_VIP_QUALITY_2
DDB_VIP_QUALITY_3
DDB_VIP_QUALITY_4
DDB_VIP_QUALITY_5
DDB_VIP_QUALITY_6
DDB_VIP_QUALITY_7
ELEMENT NAME
DESCRIPTION
