GE P4A Technical Manual page 170

Chapter 7 - Autoreclose
DDB Signal DDB Signal
Name Number
Check Sync 2 OK 884
Close in Prog 842
Control Close 839
Control Trip 838
CS AngRotACW 1594
CS AngRotCW 1595
CS1 SlipF> 1578
CS1 SlipF< 1579
CS VBus< 1583
CS VBus> 1582
CS VLine< 1580
CS VLine> 1581
CS1 AngHigh- 1593
CS1 AngHigh+ 1592
CS1 FL<FB 1591
CS1 FL>FB 1590
CS1 VL<VB 1588
CS1 VL>VB 1586
CS2 AngHigh- 1496
CS2 AngHigh+ 1495
CS2 FL<FB 1494
CS2 FL>FB 1493
CS2 SlipF< 1465
CS2 VL<VB 1589
CS2 VL>VB 1587
Dead Bus 887
Dead Line 889
DTOK All 1551
DTOK CB 1P 1552
DTOK CB 3P 1553
Evolve 3Ph 1547
Ext CS OK 900
Ext Fault Aph 1508
Ext Fault BPh 1509
Ext Fault CPh 1510
Ext Rst AROK 1517
Ext Rst CB Shots 1518
144
Source Module
Check Sync Signals (60)
CB Control (43)
CB Control (43)
CB Control (43)
Check Sync Signals (60)
Check Sync Signals (60)
Check Sync Signals (60)
Check Sync Signals (60)
Check Sync Signals (60)
Check Sync Signals (60)
Check Sync Signals (60)
Check Sync Signals (60)
Check Sync Signals (60)
Check Sync Signals (60)
Check Sync Signals (60)
Check Sync Signals (60)
Check Sync Signals (60)
Check Sync Signals (60)
Check Sync Signals (60)
Check Sync Signals (60)
Check Sync Signals (60)
Check Sync Signals (60)
Check Sync Signals (60)
Check Sync Signals (60)
Check Sync Signals (60)
System Checks Voltage Monitor (59)
System Checks Voltage Monitor (59)
Dead Time Start Enable (22)
Dead Time Start Enable (22)
Dead Time Start Enable (22)
Evolving Fault (20)
Destination Module
3 Phase AR System Check
CB Manual Close System Check
CB Control
3 Phase AR System Check
CB Manual Close System Check
Dead Time Start Enable
3 Phase AR System Check
CB Manual Close System Check
1-phase AR Dead Time
3-phase AR Dead Time Enable
1-phase AR Dead Time
3-phase AR Dead Time Enable
3-phase AR cycle selection
Autoreclose Lockout
3 Phase AR System Check
CB Manual Close System Check
Fault Memory
Fault Memory
Fault Memory
AR Reset Successful Logic
AR Shot Counters
P54A/B/C/E
P54xMED-TM-EN-1
